Troubleshooting 177
Emergency STOP buttons (red) Make sure all emergency stop
buttons are pulled out.
Hydraulics See Adjusting Pressure and Relief
Valves on page 139.
Faulty harness between packer
module and control station
Defective packer module
Hopper door open Close the hopper door.
Packer does not perform
enough cycles
Multi-cycle module
programming
Reprogram the module for higher
number of cycles (see Main Menu
on page 195).
Backup alarm and warning
buzzer inside the cab work
all the time
Tailgate proximity switch
adjustment
Adjust the proximity switch with the
tailgate cylinder (see Adjusting
Tailgate Unlocked Proximity Switch
on page 85).
Body-raised limit switch
adjustment
Adjust the limit switch rod with the
body floor (see Adjusting Body-
Raised Limit Switch on page 84).
Proximity switch Check the proximity switch with a
multimeter or
VOM for proper
operation (O
N/OFF or click).
Faulty harness Check for continuity on the
electrical harness that is connected
to the proximity switch. Change the
electrical harness if necessary.
Arm is too fast/too slow Flow limiter adjustment on
proportional valve
Recalibrate cylinder speed (see
Adjusting Arm Speed on page 226).
Flashing lights on
dashboard are always
blinking
Arm limit switch adjustment Align the lever with the gripper
finger (see Adjusting Arm Stowed
Limit Switches (2) on page 90).
Cut off or defective power
cables
Perform a continuity test on the
cable or change faulty cables.
Faulty limit switch(es) Replace faulty limit switch(es).
Arm does not respond to
joystick (assuming that the
pump switch is ON)
Cut off or defective power
cables
Follow wires on the electrical
schematic for 12-volt supply (move
joystick to get signal).
Faulty joystick Contact LabriePlus.
Problem Possible causes Solution
