16 Safety
Figure 2-7
Body safety prop
To set the body safety prop:
1. Make sure that there is enough clearance above the body to raise it safely.
2. Start the engine.
3. With the Body Up switch on the in-cab control panel, raise the body until the safety prop is free
to tilt under it.
4. Release the safety prop using the safety prop handle and position it adequately.
Figure 2-8
Safety prop handle
5. Lower the body until it rests on the safety prop using the Body Down switch on the in-cab control
panel.
6. Lock out and tag out the vehicle (see Locking Out and Tagging Out the Vehicle on page 12).
You can now work safely underneath the body.
