82 General Maintenance
Figure 3-82
Packer retract proximity switch
To verify that the switch needs adjusting, empty all refuse from the body, start a pack cycle and
observe the home position of the packer when it completes its cycle.
If the packer stops before reaching the home position or if the packer cylinders remain pressured up
or abruptly bottom out while the packer is at the home position, adjust the switch as follows.
To adjust the packer retract proximity switch:
1. Start the engine and engage the hydraulic pump.
2. Push the yellow button to retract the packer up to 1 inch from the fully retracted position
(see Figure 3-83).
Important
This procedure must be performed by two people.
Danger!
Do not enter the hopper while the packer is moving.
