Description and Operation 4-7
D-I012.1109EN
innovators in agriculture
4.2.1.6 Safety System
The JUNO 150 has a safety system to (page 2-8):
Protect people and animals against mechanical hazards by a set of
interlocking safety devices that stop the JUNO 150 immediately when
hit or openened:
Emergency stop button
Protection ring
Safety bracket
Interlocking lid.
Warn people and animals by acoustic warning device
Ensure that a fault in the hardware or software does not lead to
hazardous situations:
Hardware safety protection
Software controlled charging system
Overload protection of the drive motors
Fused control system.
Protect people during maintenance:
Sealed maintenance-free battery
Battery stop to disconnect the battery.
4.2.1.7 Control System
The control system has the following parts:
Multiboard PCB
Encoders
Ultrasonic sensor
Gyroscope (embedded on the multiboard pcb)
Inductive sensor.
All the parts work together to keep the JUNO 150 on the correct route.
Multiboard PCB
The multiboard pcb hosts the management software and controls
driving mechanism, the power system, and the shock system. It has a
gyroscope installed on it.
The multiboard pcb is installed in a box on the frame.
The E-Link manual controller, all sensors, interlocks and the emergency
stop button are connected to it.The cables for the multiboard pcb are:
The connector to the E-Link
The power supply cable
The cables to the motors
The cables to the encoders
The ultrasonic sensor cable
The inductive sensor cable
The cable tot the power energizer.
The emergency stop button cable
The cable to the interlocking protection ring
The cable to the interlocking guard
The cable to the interlocking lid.
