6-8 Operating Instructions
D-I012.1109EN
innovators in agriculture
6.7.1.4 Feed Push L
Note:
Do not program Feed push L when the fence is more than 2.5 meter (8.2 ft)
away.
1. Select the menu Feed push L and push [ ].
2. Read the actual distance to the fence (UltraDst) from the display.
3. Push [
] or [ ] to select the required distance to the fence
(ULTRADST:).
4. Push [START/STOP] to start.
5. If you want the vehicle to stop, push [START/STOP].
6. Push soft button [MAN] to modify the position.
1. Push soft button
to turn left, or to turn right.
2. Push [ESC] to confirm and go one level up.
7. Push soft button [Save].
6.7.1.5 Follow a Wall or Fence on a Certain Distance (Ultrasound)
Note:
Do not program Ultrasound L when the wall is more than 2 meters away.
Do not use this action to push feed.
1. Select the menu Ultrasound L and push [ ].
2. Read the actual distance to the wall (UltraDst) from the display.
3. Push [
] or [ ] to select the required distance to the wall
(ULTRADST).
4. Push [START/STOP] to start.
5. If you want the vehicle to stop, push [START/STOP].
6. Push soft button [MAN] to modify the position.
1. Push soft button
to turn left, or to turn right.
2. Push [ESC] to confirm and go one level up.
7. Push soft button [Save].
6.7.1.6 Go to the Charging Station following the Strip
1. Make sure the front of the vehicle is within 0.5 m (19.7 in.) from the
strip leading to the charging station, and pointing towards the strip
(page 6-4).
2. Select the menu Charger strip.
3. Push soft button [MAN] to modify the position.
1. Push soft button
to turn left, or to turn right.
2. Push [ESC] to confirm and go one level up.
4. If the charging station is on the right, push soft button [L].
