Operating Instructions 6-7
D-I012.1109EN
innovators in agriculture
6.7.1.2 Go Straight
Note:
Before starting, make sure the JUNO 150 points in the correct direction. Use
the 'Straight' option as little as possible. If it really is necessary, for example to
pass the JUNO 150 across the feed alley, make the distance travelled as short
as possible. Continue with ' Ultrasound L'. This improves the accuracy of the
route that is travelled.
1. Select Straight and push [ ].
2. Push [START/STOP] to start.
3. If you want the vehicle to stop, push [START/STOP].
4. Push soft button [MAN] to modify the position.
1. Push soft button
to turn left, or to turn right.
2. Push [ESC] to confirm and go one level up.
5. Push soft button [Save].
6.7.1.3 Turn Left or Right
1. If you want to turn left, select Turn L <-- and push [
].
2. If you want to turn right, select Turn R --> and push [
].
3. Read the message on the display and push [
].
Note:
You can choose from 9 standard turns and modify the turn afterwards.
4. Push [ ] until the most appropriate standard turn is displayed, or
push [ESC] to go to the previous display.
5. Select one of the standard turns with the appropriate soft button.
6. If you want to modify the turn, push [
] or [ ] to select the
angle.
7. If you want to drive back before making a turn:
1. Push soft button [>] to select Back.
2. Push [
] or [ ] to select the reverse distance.
8. Push [START/STOP] to start.
Note:
If the resulting turn is not exactly as planned, modify the position (see the nex
step). This is especially important if the angle is 90 or 180 degrees left or right.
9. Push soft button [MAN] to modify the position.
1. Push soft button
to turn left, or to turn right.
2. Push [ESC] to confirm and go one level up.
10. Push soft button [Save].
