Error code Description Action
202.13 Restart attempted after an internal jam without cover
open. Close event. Likely that the jam was not actually
cleared.
Go to
“Sensor (fuser exit) jam service check” on
page 58.
202.14 Expected banner sheet ( assumed wide ) not detected
by narrow media sensor, possible accordion jam,
unsupported narrow banner media, or missing signal.
Go to
“Sensor (fuser exit) jam service check” on
page 58.
202.16 Page at fuser nip before fuser started ramping toward
desired. Indicates code may be receiving more hall
interrupts than intended.
Go to
“Sensor (fuser exit) jam service check” on
page 58.
202.17 Page at fuser nip before fuser reached acceptable
operating temperature. Page arrived at fuser earlier
than expected, so it was probably staged.
Go to
“Sensor (fuser exit) jam service check” on
page 58.
202.22 Cartridge Motor - Motor Underspeed Error. Motor
made it to closed loop steady state, but then detected
speed was below threshold.
Go to
“Sensor (fuser exit) jam service check” on
page 58.
202.28 Exit sensor bounce issue. Go to
“Sensor (fuser exit) jam service check” on
page 58.
202.32 The sheet is too long to be duplexed. The blow
through is enabled.
Go to
“Duplex service check” on page 61.
202.36 Long paper or shingled multi feed stopped before
sending to duplex.
Go to
“Duplex service check” on page 61.
202.43 During warm up flush, media that passed the input
sensor failed to reach the exit sensor.
Go to
“Sensor (fuser exit) jam service check” on
page 58.
202.45 During warm up flush, sheet detected too long over
exit sensor.
Go to
“Sensor (fuser exit) jam service check” on
page 58.
Sensor (fuser exit) jam service check
Action Yes No
Step 1
Check the input sensor area for jammed media fragments.
Is the paper path free of partially fed or jammed media?
Go to step 2. Clear the paper path of
any media fragments.
Step 2
Check the fuser exit sensor cable JEXIT1 for proper connection.
Is it properly connected?
Go to step 3. Reseat the cable.
Step 3
POR into the Diagnostics menu and perform a sensor test:
Diagnostics Menu > Base Sensor Test > Exit
Does the sensor state on the control panel display change when it is
toggled?
Go to step 4. Replace the fuser. See
“Fuser removal” on
page 263.
4514-6xx
Diagnostic information
58
