LG Multi V CRUN Series User Manual

Service Manual 35
Replacement Parts List
CRNN246TDA0 CRNN286TDA0 CRNN366TDA0 CRNN426TDA0 CRNN486TDA0
354211-1 EVAPORATOR ASSY 5421A10016A R
354211-2 EVAPORATOR ASSY 5421A10016B R
352118 TUBE ASSEMBLY, MENIFOLD (INDOOR)
5211A20251B R
TUBE ASSEMBLY, MENIFOLD (INDOOR) 5211A20251H 5211A20251G R
352114 TUBE ASSEMBLY, DISTRIBUTOR 5211A10299A R
55211G TUBE ASSEMBLY, EXPANSION 5211A10298A R
158591 PUMP ASSEMBLY, WATER 5859A20001D R
266012 SWITCH ASSY, FLOAT 6601A20001F R
330870 DRAIN PAN ASSY 3087A100006A R
249951 CONTROL BOX ASSY
4995A20268X 4995A20268Y 4995A20268A 4995A20268Z 4995A10106L R
268714 PWB(PCB) ASSY, MAIN
6871A10089F F6871A10089G
6871A10089H 6871A10089S 6871A10089T R
130411 BASE ASSY, WELD INDOOR 3041A10016A R
346810 MOTOR ASSY, INDOOR 4681A20006J 4681A20006H R
359012 FAN,TURBO 5900A10003B R
140570 LOCKER 4056A20001B R
130911-1 CABINET ASSY, INDOOR 3091A10031A R
130911-2 CABINET ASSY, INDOOR 3091A10031B R
130913-1 CABINET ASSEMBLY, WELD 3091A10030A R
130913-2 CABINET ASSEMBLY, WELD 3091A10030B R
152510 DRAIN ASSY, TUBE 5251A20002B R
352150 DRAIN TUBE ASSY 5251AP2984A R
137211 PANEL ASSY, FRONT(INDOOR) 3721A10025A R
135314 GRILLE INLET 3530A10062A R
146811 MOTOR ASSY, STEP 4681A20055A R
268712 PWB(PCB) ASSY, DISPLAY 6871A20096C R
152312 FILTER ASSY 5231A10004A R
135802 DOOR LOCK 3580A20005A R
267110 WIRED REMOTE CONTROLLER 6711A10002A R
263230-1 THERMISTOR ASSY(PIPE-IN) 6323A30002A R
263230-2 THERMISTOR ASSY(PIPE-OUT) 6323AQ3226T R
263230-3 THERMISTOR ASSY(ROOM) 6323A30004C R
W0CZZ CAPACITOR 3H00660M 2A00986D R
PART NO.
DESCRIPTION
REMARK
LOCATION
NO.
