16
DESCRIPTION OF THE OPERATION
17
DESCRIPTION OF THE OPERATION
ENGLISH
Interface screen
Select the product (air conditioner or ventilation) to set using [<, >(left/right)] button.
Returning to the screen
In the main screen, after moving to the category by pressing [<, >(left/right)] button, if there is no
remote controller operation, after 10 seconds, it returns to the main screen basic position. (basic
position: indoor temperature display part)
In the screens except the main screen, if there is no remote controller operation for 1 minute, it
moves to the main screen.
When you control the air conditioner and the ventilation product
with one remote controller, the screen is displayed as in the side
figure. You can set the air conditioner by pressing [<(left)]
button and pressing [OK] button to move to the air conditioner
screen.
When you control the air conditioner and the ventilation product
with one remote controller, the screen is displayed as in the side
figure. You can set the ventilation by pressing [>(right)] button
and pressing [OK] button to move to the ventilation screen.
NOTE
!
• On the Air Quality Level screen of the ventilation product, outdoor shows the concentration
of fine dust in the air entering the ventilation product, and flow indoors shows the
concentration of fine dust in the air entering the room after passing through the filter.
• The Auto Return to Main Screen function is not run on the Air Quality Level screen.
• During group control, the Master indoor unit’s information is displayed on the screen.
• The configuration of the screen displayed may vary depending on the version of the remote
control.
※ Auto Return to Main Screen is a function that automatically returns to the main screen
when there is no touch input for a certain period of time.
- In the sub function screen, you can turn on or off the sub function supported by the product.
To Next Page
