11. Appendix MX-FR Series Modular Matrix Frames – User's Manual 178


▪ 
▪ 
3.0.9
Released: 2011-03-07
New feature
▪ 

▪ 
▪ 
3.1.0
Released: 2011-05-09
New feature
▪ MXD-HDMI-TP-OB support
▪ 
▪ Input 0 can be connected to anywhere (same as mute).
▪ Temperature measurement and show (calibration is needed).
▪ 

▪ 
▪ FR32 health status format has been changed.
▪ MX-DVID-OB CTL3 issue (barco projector compatibility)
3.1.1
Released: 2011-05-24
New feature
▪ Error message appears on the LCD in control lock mode if a key is pressed

▪ TIPO menu had sometimes shown in FR80 Frame on the LCD.
▪ Control Board freezed sometimes. (CB p:14 error)
▪ The frame works without MX-SC (LCD panel) now.
▪ 
▪ TIPO menu usage has been improved.
▪ 
▪ DVI-I board sent DVI signal in auto mode if a MX-DVI-HDCP-OB, MX-HDMI-OB or MX-HDMI-TP-OB was
present.
▪ Preview output, MX-HDMI-OB, MX-HDMI-TP-OB, MX-DVI-HDCP-OB, MXD-HDMI-TP-OB outputs
discarded audio if the sink device had been connected later than the audio content had been switched
to the output.
▪ Analog formats signalled in the emulated EDIDs were sometimes detected incorrectly.
3.1.2
Released: 2011-06-08
New feature
▪ MXD-UMX-IB support
▪ MX-DVIDL-OPT-IB support
▪ MX-DVIDL-OPT-OB support

▪ If a single-link input was connected to a dual link output then the 2nd link wasn't shut down in AUTO
mode.
▪ MX-DVI-OPT-OB 2.2 and 2.3 could cause erroneous initialization in some slots.
▪ 4-line LCD HDCP keycounter had false fail.
▪ Countermeasure against 4-line LCD sensitivity to electrostatic discharge events. (First part of the
content is read back and checked regularly, in case of discrepancy the content is refreshed.)
3.1.3
Released: 2011-07-20
New feature
▪ 
by customers.
▪ RS232, LAN and USB interfaces are independent - responses arrive to only the appropriate port, except
crosspoint commands. Please refer Lightware-CM-1001 for details.
▪ RS232 and LAN interfaces can use different protocol at same time. Please see Lightware-CM-1001 for
details.
▪ Responses to Protocol#2 switch commands are translated to Lightware protocol on the appropriate
interfaces.
▪ Protocol setup from LCD menu.
▪ "Protocol reset" in Factory reset LCD menu - it restores Lightware protocol on RS232 and LAN.
▪ 
on SD card.
▪ Improved batch command processing speed if multiple switch commands are sent at the same time.




