MX-FR Series Modular Matrix Frames – User's Manual 118
Switching and Control Commands
Operation
See in
Section
Command
Selecting the 80th Input Port 7.3.2 {TI=<value>}
Switching an Input to an Output 7.3.3 {<in>@<out>}
Switching an Input to All Outputs 7.3.4 {<in>@O}
Diagonal Switching 7.3.5 {<in>@D}
Batch Switch Outputs 7.3.6 {<in>@<out>}{<in>@<out>}
Displaying the Current Connection States of the Outputs 7.3.7 {VC}
7.3.8 {VM}
7.3.9 {#<out>}
7.3.10 {+<out>}
Disconnecting an Output 7.3.11 {0@<out>}
Disconnect All Outputs 7.3.12 {0@O}
7.3.13 {#><out>}
7.3.14 {+<<out>}
Saving a Preset 7.3.15 {$<id>}
Loading a Preset 7.3.16 {%<id>}
Preset Preview 7.3.17 {VP#<id>=?}
Renaming a Preset 7.3.18 {PNAME#<id>= <preset_name>}
Renaming an Input 7.3.19 {INAME#<in>=<input_name>}
Renaming an Output 7.3.20 {ONAME#<out>= <output_name>}
7.3.21 {PNAME#<id>=?}
7.3.22 {INAME#<in>=?}
7.3.23 {ONAME#<out>=?}
Reloading the Default Preset Names 7.3.24 {PNAME#<id>=!}
Reloading the Default Input Names 7.3.25 {INAME#<id>=!}
Reloading the Default Output Names 7.3.26 {ONAME#<id>=!}
Communication Setup Commands
Router Status Commands
System Commands
Operation
See in
Section
Command
7.4.1 {IP_CONFIG=?}
Reloading the Default IP Settings 7.4.2 {IP_CONFIG=!}
Setting a Dynamic IP Address (DHCP) 7.4.3 {IP_CONFIG=D}
7.4.4 {RS232BAUD=?}
Changing the RS-232 Baud Rate 7.4.5 {RS232BAUD=<rate>}
7.4.6 {P_?}
Changing the Control Protocol 7.4.7
{P_<protocol>}
7.4.8 {ELEVELSEND#<p>= <0>;<1>;<2>;<3>;<4>}
Operation
See in
Section
Command
7.5.1 {I}
7.5.2 {S}
7.5.3 {F}
7.5.4 {CT}
7.5.5 {GETSIZE}
7.5.6 {MAXSLOTS=?}
7.5.7 {IS}
7.5.8 {FC}
7.5.9 {LAN_VER=?}
7.5.10 {ST}
7.5.11 {ELIST=?}
Operation
See in
Section
Command
Restarting the Matrix 7.6.1 {RST}
7.6.2 {GETTIME}
Setting the CPU Time 7.6.3
{SETTIME=<date>●<time>●UTC+<zone>}
Switching the Matrix to Standby 7.6.4
Reloading the Factory Default Values and Settings 7.6.5 {FACTORY=<f1>;<f2>;…;fx}
