4. Operation MX-FR Series Modular Matrix Frames – User's Manual 60
Navigate to this menu in the main menu list and press the enter or right
► button. The monitored voltage levels, fan speeds, etc. can be scrolled
through with the up ▲ and down ▼ buttons. Press the escape button to
return to the main menu.
Router Status Menu
Navigate to this menu in the main menu list and press the enter or right
► button. This view is shown by default after powering on the LDC. Matrix
shown. Press the escape button to return to the main menu.
Card Information Menu
Navigate to this menu in the main menu list and press the enter or right
► button.
up ▲ and down ▼ buttons, and then press the enter or right ► button to
see the board information for the selected slot. Press the escape button
to return to the main menu.
The product name and version is shown of the installed board in the
selected slot. Press the escape button to return to the previous menu.
Firmware Versions Menu
Navigate to this menu in the main menu list and press the enter or right
► button. #rmwareversion
Use the up ▲ and down ▼ buttons to scroll through modules. Press the
escape button to return to the main menu.
Factory Reset Menu
This menu contains submenus that can reload factory defaults for certain
group of settings separately. After selecting an option (submenu) with the
up ▲ and down ▼ buttons, press the enter or right ► button to execute it.
the matrix. Press the escape button to return to the main menu without
any changes.
~Hardware status >>
Hardware status
CPU 3.3V: 3.32V
CPU 5V: 5.03V
Battery: 2.60V
~Router status >>
Name: 11410200
IP 192.168.002.105
Port: 10001
RS-232: 57600,8,N,1
~Card information >>
Card information
~Motherboard >>
CPU card
Input slot #1
Input slot #1
MX-DVID-IB
SCH: 2.0
PCB: 2.0
~Firmware versions>>
Firmware versions
CPU: 3.4.9r
Web server: 4.0.0
Web content: 1.7.2
~Factory reset >>
~IP reset >>
IO card reset
EDID reset
HDCP key reset
IP Reset Submenu
This operation reloads the factory default IP settings.
Parameter Default value
IP address 192.168.254.254
Port number 10001
Subnet mask 255.255.0.0
Gateway 0.0.0.0
Select YES and press the enter or right ► button to execute the operation. Select NO or press escape to
return to the previous menu without any changes.
IO Card Reset Submenu
This operation reloads the factory default settings for all input and output
execution.
Select YES to execute the operation. Select NO or press escape to return
to the previous menu without any changes.
EDID Reset Submenu
This operation emulates the factory default F49 EDID (Universal HDMI
Select YES to execute the operation. Select NO or press escape to return
to the previous menu without any changes.
This operation clears the HDCP key cache in the matrix. This is useful
when a source cannot accept as many keys as the matrix stores.
Select YES to execute the operation. Select NO or press escape to return
to the previous menu without any changes.
Protocol Reset Submenu
This operation sets the Lightware communication protocol for every
control interface (LAN, RS-232, USB). Beep sounds indicate protocol
change.
Select YES to execute the operation. Select NO or press escape to return
to the previous menu without any changes.
~IP reset >>
Reset IP settings?
~NO >>
YES
~IO card reset >>
Reset IO cards?
~NO >>
YES
~EDID reset >>
Reset EDID settings?
~NO >>
YES
~HDCP key reset >>
Reset HDCP settings?
~NO >>
YES
~Protocol reset >>
Reset Protocols?
~NO >>
YES
