4. Operation MX-FR Series Modular Matrix Frames – User's Manual 56
Supported Boards: MX-TPS-IB, -S, -A, MX-TPS2-IB-P, -AP, -SP,
MX-4TPS2-4HDMI-IB-P*, -AP*, -SP*
* only the four TPS2 ports of the boards.
Use the up ▲ and down ▼ buttons to select the parameter to be changed.
Use the left ◄ and right ► buttons to change the value.
The HDCP capability on the input port can be enabled or disabled with the
HDCP enable checkbox. #hdcp
Press enter to toggle its state.
The Test pattern generator helps test and troubleshoot video hook-ups and
displays. Use the left ◄ and right ► buttons to change the value. On turns
on, Off turns off the test pattern generator. If it is off, the output gives a
solid black, 480p video signal. (This is the default value.) In the case of No
signal mode, the output does not give any signal.
Three options can be selected for the resolutions of the TPG: 480p 60Hz,
576p 60Hz and Odd p. signal. Odd p. signal means the resolution of the test
(Input 1 for the input 1 and 2, Input 3 for input 3 and 4, and so on…) If there
is no video signal on the odd input, the generator gives a 480p signal.
#nosyncscreen #testpattern
The pattern can be solid green, blue, black, white or black and white ramp and
chessboard or color bar. The cycle changes all the listed ones periodically.
The Audio mode settings are available in the case of the MX-TPS-IB-A and
MX-TPS-IB-S boards. It can be selected here which is embedded in the
forwarded HDMI signal: it can be set to No audio (A), HDMI audio passth. (B),
Embed from Ext (C), Deembed to Ext (D) or HDMI + deemb (E).
For detailed information about the audio settings, see the Audio Options
section. #analogaudio #audio
The Analog Audio Input settings are available in the case of the MX-TPS-IB-A
board. The submenu contains the attributes of the analog audio signal.
volume, balance, gain, phase (invert), DC Filter.
In the case of output (deembed), the options are: volume, balance, bass,
treble, deemphasis, phase (invert), DC Filter.
The TPS mode can be HDBaseT, Longreach, Automatic, RS232 only and
RS232+ETH only.
Input 7 settings
~HDCP enable [*]~
TPG mode
Off
Input 7 settings
HDCP enable [*]
~TPG mode ~
~<No signal mode >~
Input 7 settings
On
~TPG clk ~
~<Odd p. Signal >~
Input 7 settings
Input (odd p.)
~TPG pattern ~
~<Color bar >~
Input 7 settings
Color bar
~Audio mode ~
~<HDMI + deembed >~
Input 7 settings
Audio mode
HDMI + deembed
~Analog Audio Inpu>>
Analog Audio Input~
~Volume ~
~< 0 dB >~
Balance
Input 7 settings
Analog Audio Input.
~TPS mode ~
~<HDBaseT >~
For detailed information about the TPS modes, see the TPS Link Modes
section.
The PoE setting (remote Power over Ethernet) is available only in the case
of TPS2 boards. Set the desired mode (enable/disable) on the given port.
#gain #nosyncscreen #testpattern
Supported Boards: MX-HDMI-3D-IB, -S, -A; MX-DVI-4K-IB
Use the up ▲ and down ▼ buttons to select the parameter to be changed.
Use the left ◄ and right ► buttons to change the value.
The HDCP capability on the input port can be enabled or disabled with the
HDCP enable checkbox.
Press enter to toggle its state.
The Test pattern generator makes it simple to test and troubleshoot video
hook-ups and displays. Use the left ◄ and right ► buttons to change the
value. On turns on, Off turns off the test pattern generator. If it is off, the
output gives a solid black, 480p video signal. (This is the default value.) In
the case of No signal mode, the output does not give any signal. #hdcp
Three options can be selected for the resolutions of the TPG: 480p 60Hz,
576p 60Hz and Odd p. signal. Odd p. signal means the resolution of the test
(Input 1 for the input 1 and 2, Input 3 for input 3 and 4, and so on…) If there
is no video signal on the odd input, the generator gives a 480p signal.
The pattern can be solid green, blue, black, white or black and white ramp and
chessboard or color bar. The cycle changes all the listed ones periodically.
The Audio mode settings are available in the case of the MX-HDMI-3D-IB-A
and MX-HDMI-3D-IB-S boards. It can be selected here which is embedded
into the forwarded HDMI signal: it can be set to No audio (A), HDMI audio
passth. (B), Embed from Ext (C), Deembed to Ext (D) or HDMI + deemb (E).
The Analog Audio Input settings are available in the case of an MX-TPS-IB-A
board. The submenu contains the attributes of the analog audio signal.
#audio #analogaudio
input (embed), the options are:
volume, balance, gain, phase (inversion), DC Filter.
In the case of output (deembed), the options are: volume, balance, bass,
treble, deemphasis, phase (inversion), DC Filter.
Input 17 settings
Automatic
~PoE ~
~<Disable >~
Input 3 settings
~HDCP enable [*]~
TPG mode
Off
Input 3 settings
HDCP enable [*]
~TPG mode ~
~<No signal mode >~
Input 3 settings
On
~TPG clk ~
~<Odd p. Signal >~
Input 3 settings
Color bar
~Audio mode ~
~<HDMI + deembed >~
Input 3 settings
Input (odd p.)
~TPG pattern ~
~<Color bar >~
Input 3 settings
Audio mode
HDMI + deembed
~Analog Audio Inpu>>
Analog Audio Input~
~Volume ~
~< 0 dB >~
Balance
