General
Compliance ....................................................................................... CE
 .......................................... EN 55035:2017, EN 55032:2015
Safety .........................................
 ..................................................................................... 3 years
Operating temperature ...................................................... 0°C ~ +50°C
Humidity ............................................................................ 10 ~ 90% RH
Power source ................................................. 100-240 V AC; 50~60 Hz

MX-FR80R and MX-FR65R
Power consumption ...............................
Power supply unit(s) type ................................................ FNP850-12RG
Rack mount ....................................................................... Yes, 15U high
Dimensions (mm) .................................................
Dimensions (inch) ..............................................
 ....................................................27.6 kg
MX-PSU-850 ...................................................................................1.4 kg
MX-FR33R
Power consumption ................................
Rack mount ....................................................................... Yes, 7U high
Dimensions (mm) ................................................
Dimensions (inch) ..............................................
 ....................................................33,9 kg
MX-PSU-350 ......................................................................................1 kg
MX-FR33L
Power consumption ..................................
Rack mount ....................................................................... Yes, 6U high
Dimensions (mm) .................................................
Dimensions (inch) ..............................................
 ....................................................11.6 kg
MX-FR17, MX-FR9
Power consumption ..................................
Rack mount ....................................................................... Yes, 4U high
Dimensions (mm) .................................................
Dimensions (inch) ................................................ 
 ....................................................10.8 kg
I/O ports

Connectors .................................................... 29-pole DVI-I digital only
Input cable equalization ................................................................... No
EDID emulation ................................................................................ Yes
Reclocking .............................................Yes, Pixel Accurate Reclocking

Connectors ..................................................... 29 pole DVI-I digital only
Output pre-emphasis ......................................................................... No
Reclocking ............................................ Yes, Pixel Accurate Reclocking
EDID read ........................................................................................... Yes
+5V output current .................... 500 mA continuous each (protected)
Signal
Data rate: ........
Channels: ....................................... 1x TMDS Clock + 3x TMDS Colors
Resolutions: ............. all between 640x480 and 1920x1200@60Hz or
...................................................................................2048x1080@60Hz
Color depth: ......................................... 
Color format .............................................................. RGB, YCbCr 4:4:4
HDTV resolutions: .................................................. 720p, 1080i, 1080p
HDMI 1.3a compatible: .................................... Yes (embedded audio)
HDCP compliant: .............................................................................. Yes




