Lightware MX-FR Series

 MX-FR Series Modular Matrix Frames – User's Manual 112
Input Port Parameters
Supported Boards:
▪ MX-TPS-IB-A, -AP; MX-TPS-OB-A, -AP
▪ MX-4TPS2-4HDMI-IB-A; MX-4TPS2-4HDMI-IB-AP
▪ MX-HDMI-3D-IB-A; MX-HDMI-3D-OB-A
▪ MXD-UMX-IB
Description:

The actual setting is in the response; see the legend for the details.
Setting the Parameters
The 'Volume' is changed to 0 dB, the others left unchanged.
Legend
Format 
Command 
→
{:AUDIN#9@SI=?}
Response
  =<vol>;<bal>;
<gain>;<ph>;<res>;)CrLf
←
(AUDIN#9@SI=6300;50;0;0;0;)CrLf
Format 
Command  <vol>;
<bal>;<gain>;<ph>;x }
→
{:AUDIN#9@SI=0}
Response
  =<vol>;<bal>;
<gain>;<ph>;<res>;)CrLf
←
(AUDIN#9@SI=0;50;0;0;0;)CrLf
 Parameter Description Parameter Values
<vol> Volume level
Values are accepted between -63 and 0 dB (step is 1
dB) and rounded. e.g. 6000 = -60 dB; 3625 = -36 dB
<bal> Balance
Values are accepted between 0 and 100 (step is 1):
e.g. 50 = center (default)
<gain> Gain (input volume level) Accepted values: 0, 3, 6, 9, 12, 15, 18, 21, 24
<ph>
The phase invert of the
outgoing signal
0 = disabled
1 = enabled
<res> Reserved
DVI-DL Output Port
Supported Boards:
▪ MX-DVIDL-OB
Description:
Port Parameters and Settings

 The actual setting is in the response.
Setting the Parameters
The DVI port mode is changed to Dual link mode, the others left unchanged. Use the 'x' character
to keep the actual value of a parameter.
Legend

by the fourth parameter.
Format 
Command 
→
{:ISL54105#9@SO=?}
Response
(ISL54105#9@SO=<curr>;<preemp>;
<band>;<mode>;)CrLf
←
(ISL54105#9@SO=7;15;2;2;)CrLf
Format 
Command 
→
{:ISL54105#9@SO=x;x;x;0}
Response
(ISL54105#9@SO=<curr>;<preemp>;
<band>;<mode>;)CrLf
←
(ISL54105#9@SO=7;15;2;0;)CrLf
 Parameter Description Parameter Values
<curr> Output level
Port-related parameters (internal use)<preemp> PreEmphasis
<band> PLL bandwidth
<mode> 
0 = Dual-link mode is active
1 = Sinlge-link mode is active
2 = Auto mode (the dual-link half controlled
automatically depending on the input signal)




