4. Operation MX-FR Series Modular Matrix Frames – User's Manual 54

Save Settings
Any changes made in the IP settings menu come alive only when Save
settings is executed. To do this, navigate to this item with the up and
down buttons, then press the enter or right buttons.
The Operation in progress message appears on the LCD. If saving the
settings succeeds, the Operation done! message is shown for 2 seconds.
INFO: If you get the Operation Failed message, please try again.
RS-232 Settings Menu
The serial port baud rate value can be set here. Use the left and right
buttons to change the baud rate value. Changes take place immediately
when modifying the value. Press the escape button to return to the main
menu.
#rs232 #rs-232 #serial
Protocol Settings Menu
Navigate to this menu in the main menu list and press the enter or the
right button to set the communication protocol for each interface
separately.
Use the up and down buttons to select an interface, and then select
the desired protocol with the left and right buttons. Changes take
place immediately when modifying the value. A beep sound indicates that
the protocol is changed.
Press the escape button to return to main menu.
Input Settings Menu
Navigate to this menu in the main menu list and press the enter or right
button.
Select Input Port Submenu
Use the up and down buttons to select the port that needs adjustment
and then press the enter or right button.
The items in the following submenu depend on the interface board type,


Supported Boards: MX-DVID-IB, MX-DVI-TP-IB(+)
The input cable equalization can be set in 0.1dB increments from 0 dB to
41.0 dB, or Auto. Use the left and right buttons to change the value.
IP SETTINGS
Default gateway
Subnet mask
~Save settings >>
~RS-232 settings >>
RS-232 settings
~Baud rate: ~
~<57600 >~
~Protocol settings>>
Protocol settings
~LAN: ~
~<Lightware >~
RS-232:
Protocol settings
Lightware
~RS-232: ~
~<Protocol #2 >~
~Input settings >>
Select input
Input 1
~Input 2 >>
Input 3
Input 1 settings
~Equalization ~
~< 40.7 dB >~

Supported Boards: MX-HDMI-IB, MX-DVI-HDCP-IB, MX-HDMI-TP-IB, MX-
CPU2 Test input
Use the up and down buttons to select the setting to be changed.
The input cable equalization can be set to 3, 9, 25, 35, 40 dB, or Auto.
Use the left and right buttons to change the value. (exception: the MX-
CPU2 Test input port does not have cable equalization.)
The HDCP capability on the input port can be enabled or disabled with the
HDCP enable checkbox. Press enter to toggle its state.
The Color range conversion can be set to compress, expand or Auto. Use the
left and right buttons to change the value.

Supported Boards: MX-DVII-HDCP-IB, MXD-UMX-IB
Use the up and down buttons to select the parameter to be changed.
Use the left and right buttons to change the value.
The Interface parameter sets the signal type that is connected to the input
port. It can be set to Auto, Analog auto, Analog RGB, Analog YUV, or Digital.
The Port mode setting affects the signal type that is sent to the crosspoint.
All incoming analog signals are digitized on the input. DVI or HDMI signal
can be sent to the crosspoint. This parameter can be xed DVI or pass HDMI.
The latter option uses HDMI signal if the incoming signal is HDMI as
well. #hdcp
The Audio source parameter is accessible only with the MXD-UMX-IB. It can
be set to No Audio, DVII (embedded audio) or Add-on. The latter option takes

the Add-on source setting. The HDCP capability on the input can be enabled
or disabled with the HDCP enable setting. The Analog settings submenu
affects the analog video input parameters.
Input 9 settings
~Equalization ~
~< Auto >~
HDCP enable [*]
Input 9 settings
Equalization
Auto
~HDCP enable [*]~
Input 9 settings
HDCP enable [*]
~Color range ~
~<Compress >~
Input 2 settings
~Interface ~
~<Auto >~
Port mode
Input 2 settings
~Port mode ~
~<pass HDMI >~
Audio source
Input 2 settings
~Audio source ~
~<DVII >~
HDCP enable
Input 2 settings
~HDCP enable ~
~<Enabled >~
Analog settings
Input 2 settings
HDCP enable
Enabled
~Analog settings >>
