Lightware MX-FR Series

 MX-FR Series Modular Matrix Frames – User's Manual 90

Description: 

 The matrix has an MX-CPU2 processor. There is a control panel in the frame.

Description: Shows information about the LAN interface.
Legend:
 MAC address, webcontent and webserver versions are shown.

Description: 
Internal voltages, temperature and fan speeds shown.
Format 
Command {FC}
→
{fc}
Response (CF●<DESC>)CrLf
(CF●<DESC>)CrLf
…
(CF END)CrLf
←
←
←


…
(CF END) CrLf
Format 
Command {LAN_VER=?}
→
{lan_ver=?}
Response (MAC_ADDR=<mac>)CrLf

(SERVER_VER=<ver2>)CrLf
←
←
←
(MAC_ADDR=00-20-4A-C7-AC-C0)CrLf

(SERVER_VER=4.0.0)CrLf
 
<mac> MAC address of LAN controller in the matrix.
<ver1> Version of built-in website user interface (webcontent).
<ver2> 
Format 
Command {ST}
→
{st}
Response (ST●<DESC>)CrLf
…
(ST●<DESC>)CrLf
←
←
←
ST CPU 3.32V 5.03V 3.05V 5.03V
12.11V 31.6C)CrLf
(ST FAN#1 1530RPM)CrLf
(ST FAN#2 1530RPM)CrLf

Description: Shows the basic error list since last boot up.
 There are no errors only standard notices that occur on boot up.
Legend:
INFO: 
mean that there is any problem with the matrix!
System Commands

Description: The matrix router can be restarted without unplugging power.
 The matrix reboots and sends a message when it is ready.
Legend: <name> is the type of the matrix.
INFO: The response can be seen only if the connection to the router is still alive.
Format 
Command {ELIST=?}
→
{elist=?}
Response (ELIST#<num>● <elevel>●<code>●
<param>●<occ>)CrLf
…
(ELIST#<num>● <elevel>●<code>●
<param>●<occ>)CrLf
←
←
←
←
←
(ELIST#1 Notice BOOT p:2 o:1)CrLf
(ELIST#2 Notice SERIAL p:0 o:1 )CrLf
(ELIST#3 Notice CARDINIT p:81 o:1 ) CrLf
(ELIST#4 Notice CARDINIT p:2 o:1 )CrLf
(ELIST#5 Notice READY p:0 o:1)CrLf
 
<num> Line number
<elevel>
NOTICE: Not an error, Initialization information

operation
MATTER: Problem that may lead to further errors
ERROR: Serious error, must report to Lightware support
FATAL: Fatal error, normal operation is not possible
<code> Short name for type of log entry
<param> Technical parameter
<occ> Occurence number for this type of log entry
Format 
Command {RST}
→
{rst}
Response (Booting…)CrLf
(<name>●Ready!)CrLf
←
(Booting…)CrLf
(MX-FR17 Ready!)CrLf




