Lightware MX-FR Series

 MX-FR Series Modular Matrix Frames – User's Manual 102


Format:
 E1400
                
resolution running without errors. The forwarded signal is DVI.
<in_set> block
You are able to verify the actual settings on the selected input ports with this block as this block is always

Format: PX<HDCP_mode><TPG_mode><TPG_clock><TPG_screen><Audio_mode>
 Parameter Description Parameter Values
<addon>
The type of the installed
audio add-on board
0 = no add-on board is installed
1
2 = add-on type is stereo (UDA)
3 = add-on type is stereo (ADAV)
F = add-on type is stereo but initialization is failed
<TPG_res>
The resolution of the test
pattern
0 = Test pattern generator is inactive
3 = active, the resolution is 720x576p@50Hz
4 = active, the resolution is 720x480p@60Hz
<TPG_alert>
Test pattern alert
information
0 = no error
1 = unsupported resolution is detected
<FW_mode>
The forwarded signal mode
from the board
0 = DVI
1 = HDMI, 24 bit
2 = HDMI, 30 bit
3 = HDMI, 36 bit
4 = HDMI, 48 bit
 Parameter Description Parameter Values
 HDCP mode setting 0 = HDCP is disabled 1 = HDCP is enabled
<TPG_mode>
The mode of the Test
pattern generator
0 = off, test pattern is not sent (default)
1 = on, test pattern is always sent
2 = test pattern is sent if there is no incoming signal
<TPG_clock>
The resolution of the test
pattern
0 = 720x480p60
1 = 720x576p50
2 = the same as the
incoming signal *
<TPG_screen> The type of the test pattern
0 = solid red
1 = solid green
2 = solid blue
3 = solid black
4 = solid white
5 = ramp
6 = chessboard
7 = color bar
8 = cycle (the patterns
are switched in every two
seconds)
<Audio_mode>
Audio mode setting of the
installed add-on board **
A = no audio
B = HDMI passthrough
C = Embed from external
D = Deembed to external
E = HDMI + deembed
* The supported resolutions in the case of the test pattern generator: 480p60, 576p50, 720p50, 720p60,
1080p50, 1080p60.
** See more information about the Audio modes in the Audio Settings section.
 PX1007B
HDCP is enabled; Test pattern generator is off; the original audio of the HDMI signal is embedded
(passthrough).
Timing Parameters
Supported Boards:
▪ MX-HDMI-3D-IB, -A, -S
▪ MX-4TPS2-4HDMI-IB, -A, -S; MX-4TPS2-IB-P, -AP, -SP
Description: The system continuously measures the parameters of the incoming signals. The answer
consists of 16 data bytes and every data byte is represented as a two-digit hexadecimal number. The
parameters could be useful for advanced debugging processes.

For more information about the measured values, please contact Lightware Support.

Port Parameters and Settings
Supported Boards:
▪ MX-HDMI-OB; MX-DVI-HDCP-OB; MX-HDMI-TP-OB
Description: 

The actual settings are in the response; see the legend of each block for the details.
Format 
Command 
→
{:TIMINGS#17@SI=?}
Response 
<Timing_codes>)CrLf
←
(TIMINGS#17@SI=0360027102
D002402C0501004008630C)CrLf
Format 
Command 
→
{:HDMI#1@SO=?}
Response 
<VIDEO>;<ADV_INFO>;<OUT_SET>;
<SINK>;)CrLf
←
(HDMI#1@SO=G11101;V720x576p51,313,00;
I0011AA;OAAAAA;M110111077;)CrLf




