11. Appendix MX-FR Series Modular Matrix Frames – User's Manual 133
Control
Front Panel buttons .......................................................................... Yes
Serial port connector ............. 9 pole D-SUB female RS-232 or RS-422
Baud rate ................................... 57600 Baud, 8 bit, 1stop bit, no parity
Ethernet port connector ...............
Ethernet protocol ........................................
IP address assignment .......................
Alarm output connector .......................... SMPTE 269M standard BNC
............................................................................................. 0.9 kg
Control over Fiber and TPS
Selectable baud rate ........................................................................ Yes
Baud rate .................................................. 9600, 19200, 36800, 57600
............................... Maximum 54 byte
Maximum bandwidth ....................................................
* (RS-232, IP and USB control altogether)
frequencies up to 148.5 MHz.
20% shorter.
To specify the accurate extension distances, please also check the
documentation of the connected HDBaseT-compatible device.
Resolution
Cable Lengths
CAT5e
AWG24
CAT7
AWG26**
CAT7
AWG23
1024x768@60Hz 65
130 m*
120 m*
170 m*
1280x720p@60Hz 73.8
130 m*
120 m*
170 m*
1920x1080p@60Hz
148.5
130 m*
120 m*
170 m*
1920x1200@60Hz 152.9
NA
NA
NA
1600x1200@60Hz 162
NA
NA
NA
36bpp
223.6
NA
NA
NA
3840x2160@30Hz
UHD
297
NA
NA
NA
4096x2160@30Hz
4K
297
NA
NA
NA
Resolution
CAT5e
UTP
CAT5e
FTP
CAT6
UTP
CAT6
FTP
CAT6
SFTP
CAT7
SFTP
640x480@60 60 m 60 m 65 m 70 m 70 m 80 m
800x600@60 60 m 60 m 65 m 65 m 65 m 75 m
1024x768@60 55 m 55 m 60 m 60 m 60 m 75 m
1280x720p60 55 m 55 m 60 m 60 m 60 m 70 m
1280x1024@60 50 m 50 m 55 m 60 m 60 m 65 m
1400x1050@60 45 m 45 m 45 m 55 m 55 m 60 m
1600x1200@60 30 m 35 m 35 m 45 m 45 m 50 m
1920x1080p60 30 m 35 m 35 m 45 m 45 m 50 m
1920x1200p60 30 m 35 m 35 m 45 m 45 m 50 m
Factory Default Settings
Network Settings
IP address 192.168.254.254
Subnet mask 255.255.0.0
Static gateway 0.0.0.0
DHCP Disabled
10001
HTTP Port number 80
Control protocol
Video Port Settings
Crosspoint state I1 input port on all output ports
Unmuted, Unlocked
Emulated EDID (input ports) F49 – Universal HDMI EDID
EDID memory Empty (User and Dynamic EDIDs)
Crosspoint presets All outputs to I1
Preset names Preset1, Preset2,...
Port names Input1, Input2...; Output1, Output2...
RS-232 Settings
Baud rate 57600
Databits 8
Parity No
Stopbits 1
Control protocol
