1. Introduction MX-FR Series Modular Matrix Frames – User's Manual 7
Features of the Device
The router allows any input to be switched to any
output or more outputs simultaneously.
video sources and displays.
The MX Series supports the highest 4K UHD,
2560x1600 and 1920x1080@120Hz resolutions,
standard HDMI 3D formats and all HDMI 1.3
resolutions, operating without signal latency.
1080p
HDTV
720p, 1080i and 1080p etc. signals are supported with
or without HDCP encryption.
3D Support
Lightware provides complex, integrated solutions for
the digital age, also delivering 3D content in the case of
UMX Technology
UMX (Universal MatriX) technology was developed
to support various analog and digital video and
audio signal formats with several input connection
possibilities.
HDCP-encrypted and non-HDCP components can be
installed in the same system within the same chassis.
No Signal Latency With Zero Frame Delay
The signal management architecture ensures that there
is no delay added between the input and the output.
Advanced EDID Management
The user can emulate any EDID on the inputs
independently, read out and store any attached
monitor's EDID in the internal memory locations.
Built-in Cable Compensation
Each DVI, HDMI or SDI input port contains an individual
built-in cable extender.
Each output has a clean, jitter free signal, eliminating
signal instability and distortion caused by long cables
Frame Detector and Signal Analysis
The exact video and audio signal format can be
determined such as timing, frequencies, scan mode,
HDCP encryption, color range, color space and audio
sample rate.
This technology is designed to switch inputs remotely
on Lightware signal extenders without any additional
control cabling. The RICOD master device can control
the RICOD slave device connected to its input port.
DVI +5V Power Support
500 mA constant current output on each DVI or HDMI
other DVI powered devices.
Redundant Power Supply
Accepting AC voltages from 100 to 240 Volts with 50
or 60 Hz line frequency on standard IEC connector.
Redundant hot-swappable PSUs on selected models.
Power Failure Memory
settings when powered on or after a power failure.
Every setting is stored in a non-volatile memory.
Front Panel Control
Sources and destinations have their own button to
select. Single switches can be executed or crosspoint
presets can be saved and reloaded. Almost every
menu.
The latest edition of LDC got more intuitive, user
friendly, smarter and a modern user interface to control
the Lightware devices. The application is available for
Built-in Website
Easy access from a web browser to control and
allowed to install.
Ethernet Control
with simple ASCII based protocol for controlling and
USB Control
RS-232
RS-232 or RS-422 Control
Simple ASCII-based protocol can be used for switching,
preset calling, status request, etc.
TPS Cable Diagnostic Tool
The tool within the LDC software will help you identify
potential twisted pair cable issues in your TPS-capable
(HDBaseT
®
-compliant) system.
