CHAPTER 4: OPERATION 5
MOVE S2
A 4.875/4.6 Remote control
B Electrical cabinet
M1 2.210.150 Hydraulic pump motor
M2 4.706 Servo motor (cable directly to the electrical cabinet)
M3 4.886 Chain loader motor 220/400 VAC
M5 4.307 Diameter setup motor for dropping fingers
QS1 4.242 Main disconnect switch
SP1 3.638 Air pressure switch
SP2 4.050 Hydraulic pressure switch
SQ1 4.772 Measuring cell (optical cell)
SQ3 4.968 Pusher support in open position switch
SQ4 4.968 Pusher support in closed position switch
SQ5 4.391 Pusher in home position switch
SQ6 4.968 Bar stock laying fingers down position control
SQ7 4.968 Bar stock laying fingers up position control
SQ8 4.391 Chain loader indexing switch
SQ9 4.772 Bar stock presence proximity switch
SQ10 4.484 Retract system safety switch
SQ11 4.484 Main access cover closed switch
SQ13 4.391 Dropping fingers reference
SQ14 4.391 Referencing for dropping fingers proximity switch
SQ15 4.763 Chain loader protection safety switch
SQ16 4.773 Safety switch : light beam on chain loader
