CHAPTER 1 PRODUCTION DESCRIPTION
6
PTE2D Single bi-directional fiber 1.25G 1550nm LC with DDM 20 Km
PTD4D Single bi-directional fiber 1.25G 1310nm LC with DDM 40 Km
PTE4D Single bi-directional fiber 1.25G 1550nm LC with DDM 40 Km
PTD6D Single bi-directional fiber 1.25G 1310nm LC with DDM 60 Km
PTE6D Single bi-directional fiber 1.25G 1310nm LC with DDM 60 Km
PTD8D Single bi-directional fiber 1.25G 1310nm LC with DDM 80 Km
PTE8D Single bi-directional fiber 1.25G 1310nm LC with DDM 80 Km
Combo Gigabit Ethernet(GbE) Interface
Number of Ports 2
Speed 10/100/1000M Base T
Connector RJ45 for twisted pair GbE, LC for optical GbE, auto detection
Gigabit Ethernet(GbE) Interface
Number of Port 2
Speed 10/100/1000M Base T
Connector RJ45
Ethernet Function
MDI/MDIX for 10/100/1000M BaseT auto-sensing Basic Features
Ping function contained ARP
Per port, programmable MAC hardware address learn limiting (max. MAC table
8192 (8k) entry)
Packet Delay Variation:
- Unframed T1: Up to 340 ms
- Framed T1: Up to 256 ms
- E1:up to 256 ms
- Framed T1 with CAS: Up to 192 ms
Packet Transparency Packet transparency support for all types of packet types including IEEE 802.1q
VLAN and 802.1ad (Q-in-Q)
QoS User configurable 802.1p CoS, ToS in out going IP frame
Ingress packet Rate limiting buckets per port for ethernet port
Traffic Control
Supporting Rate-based and Priority-based rate limiting for LAN port
Granularity:
a. From 64 Kbps to 1 Mbps in increments of 64 Kbps
b. From 1 Mbps to 100 Mbps in increments of 1 Mbps
c. From 100 Mbps to 1000 Mbps in increments of 10Mbps
Pause frame issued when the traffic exceeding the limited rate before packet
dropped following IEEE802.3X
Jitter & Wander
PPM: per G.823 Traffic
PPB: per G.823 Synchronous
Standard Compliance
IETF TDMoIP (RFC5087), SAToP (RFC4553), CESoPSN (RFC5086)
IEEE 802.1q, 802.1p, 802.1d, 802.3, 802.3u, 802.3x, 802.3z, 802.1s, 802.1w
