¾ Tributary Setup Screens:
When you enter this section, you will first see the Tributary Setup menu. Use arrow keys to select the
action you need.
SLOT 2 TDMoE === Tributary Setup === 16:21:41 12/31/2009
Select Action >> *Trib1 Trib2 Trib3 Trib4
Press Enter key. You will see the screen below.
T1
SLOT 2 TDMoE === Tributary Setup === 16:29:58 12/31/2009
ARROW KEYS: CURSOR MOVE, TAB: ROLL OPTIONS
Framing Mode : T1-None
CAS : Off
ARP on Remote Loss: Continue
NOTE: Send ARP Packet after remote unit is undetached
<< Press ESC key to return to previous menu >>
E1
SLOT 2 TDMoE === Tributary Setup === 08:43:26 01/12/2010
ARROW KEYS: CURSOR MOVE, TAB: ROLL OPTIONS
Framing Mode : E1-Unframe
CAS : Off
ARP on Remote Loss: Continue
NOTE: Send ARP Packet after remote unit is undetached
<< Press ESC key to return to previous menu >>
Note: If the Framing Mode of a port is framed, and “TSI Map Setup” in AM3440 Controller Menu ((S)
System Setup > (C) TSI Map) is configured, you need to clear TSI Map (AM3440 Main Menu >
(S) System Setup > (F) Clear a TSI Map) and delete bundle(s) of that port before changing
settings of Framing Mode and CAS.
Table 7-21 Tributary Configuration Setup (Trib1, Trib2, Trib 3, Trib4)
Field Setting Options Default
T1 T1-None, T1-T1403, T1-ESF, T1-D4 T1-None Framing Mode
E1 E1-Unframe, E1-FAS E1-Unframe
CAS On, Off On
ARP on
Remote Lose
Continue, Stop Continue
After you change the options, press ESC. A prompt will ask if you wish to change configuration. Press Y
to confirm.
Change configuration (Y/N)? (Note:to save,please use V-command)
When the RSTP configuration is changed successfully, the screen will return to the previous page.
