CHAPTER 7 SYSTEM SETUP
34
ARROW KEYS: CURSOR MOVE, Please Input: 0~100, BACKSPACE to edit
P0 queue P1 queue P2 queue P3 queue
Weight: 007% 013% 027% 053%
NOTE: The sum of weights must equal 100
<< Press ESC key to return to previous menu >>
After you enter new WRR Weight for each queue, press Esc. A prompt will ask if you wish to change
configuration. Press Y to confirm.
Change configuration (Y/N)? (Note:to save,please use V-command)
When the configuration is successfully changed, the screen will return to the previous menu.
7.2.2.3. Rate Control Setup
¾ Command Path
Main Menu > (S) System Setup > (C) Qos Setup > (C) Rate Control
Setup
¾ Function
Rate Control/Limit: Rate Control/Limit is applied to manage the
transmission bandwidth of data flow from an
interface to its buffer. When the transmission
bandwidth of the ingress traffic exceeds the
preconfigured data rate, the exceeded portion of
ingress traffic will be dropped. For example, if
the speed of a Fast Ethernet port is 100 Mbps
and the rate limit is configured as 80 Mbps, then
only 80 Mbps of data can be forwarded to the
buffer. If there is a bursty traffic of 90Mbps, 10
Mbps of data will be dropped.
Table 7-10 Rate Control Setup
Port Setting Options Default
When the Ethernet speed is 10M
ETH1~4 1-15 x 64kbps
1-10 x 1Mbps
00 x 64kbps
When the Ethernet speed is 100M
ETH1~4 1-15 x 64kbps
1-100 x 1Mbps
00 x 64kbps
When the Ethernet speed is 1000M
ETH1~4 1-15 x 64kbps
1-100 x 1Mbps
10-100 x 10Mbps
00 x 64kbps
¾ Rate Control Setup Screens:
Using BACKSPACE to edit and enter decimal numbers and speed for each port:
SLOT 2 TDMoE === Rate Control Setup === 14:34:06 12/31/2009
Please input decimal number(1~15), BACKSPACE to edit
ETH1: 00 x 64kbps
ETH2: 00 x 64kbps
ETH3: 00 x 64kbps
ETH4: 00 x 64kbps
<< Press ESC key to return to previous menu >>
After you enter decimal number and speed for each port, press Esc. A prompt will ask if you wish to
change configuration. Press Y to confirm.
Change configuration (Y/N)? (Note:to save,please use V-command)
