CHAPTER 6 SYSTEM STATUS
16
6. SYSTEM STATUS
This chapter shows the DISPLAY section on VT100 Main Menu. This is where you can get the
information about current system status. You can also check your settings here after you do the setup
configuration in the SETUP section.
Note: The screen for System Configuration Display should correspond to the System Setup page; Time
Slot IP Configuration should correspond to Time Slot IP Assignment.
6.1. 15-Min/1-Hr/7 Days Perf. Report
¾ Command Path
Main Menu > (1) 15-Min/1-Hr/7 Days Perf. Report
¾ Description
Display the 15-Min/1-Hr/7 Days performance report
Table 6-1 15-Min/1-Hour/7 Days Perf Report
Field Setting Options Default
Register Port Trib1~4 Trib1
E1 00~31 00 Register Bundle
T1 00~24 00
¾ 15-Min/1-Hr/7 Days Perf. Report Screens:
Use arrow keys to select a port and a bundle and press Enter key:
SLOT 2 TDMoE === 15-Min/1-Hr/7 Days Perf.Report === 12:53:06 12/30/2009
ARROW KEYS: CURSOR MOVE, TAB: ROLL OPTIONS
Register Port :Trib1
Register Bundle :00
<< Press ESC key to return to previous menu >>
Then you will see the 15-Min/1-Hour/7 Days Perf. Report for the port and bundle you select listed as
below:
SLOT 1 TDMoE === 15-Min/1-Hr/7 Days Perf.Report === 13:42:29 12/29/2010
Trib 1 Bundle 0
-- Valid Seconds in Current 15-Min Interval: 0 seconds
Rx-Lost J-UR J-OR
Current 15-Min Interval : 0 0 0
1st Nearest 15-Min Interval: ----- ----- -----
2nd Nearest 15-Min Interval: ----- ----- -----
3rd Nearest 15-Min Interval: ----- ----- -----
4th Nearest 15-Min Interval: ----- ----- -----
-- Valid 15-Min Intervals in Current 24-Hour Interval: 0
Rx-Lost J-UR J-OR
Current 24-Hour Interval: 3 ----- -----
12/28/2010 : 3 ----- -----
12/27/2010 : ----- ----- -----
12/26/2010 : ----- ----- -----
12/25/2010 : ----- ----- -----
12/24/2010 : ----- ----- -----
12/23/2010 : ----- ----- -----
12/22/2010 : ----- ----- -----
<< TAB key to show Statistics Report >>
<< ESC key to return to previous menu, SPACE bar to refresh >>
