Loop Telecom AM3440 series User Manual

CHAPTER 7 SYSTEM SETUP
45
¾ Time Slot Assignment Setup Screen:
SLOT 2 TDMoE === Time Slot Assignment Setup 18:31:33 01/05/2010
ARROW KEYS: CURSOR MOVE, TAB: ROLL OPTIONS
Port:Trib1
TS0 : Idle TS16: Idle
TS1 : Idle TS17: Idle
TS2 : Idle TS18: Idle
TS3 : Idle TS19: Idle
TS4 : Idle TS20: Idle
TS5 : Idle TS21: Idle
TS6 : Idle TS22: Idle
TS7 : Idle TS23: Idle
TS8 : Idle TS24: Idle
TS9 : Idle TS25: Idle
TS10: Idle TS26: Idle
TS11: Idle TS27: Idle
TS12: Idle TS28: Idle
TS13: Idle TS29: Idle
TS14: Idle TS30: Idle
TS15: Idle TS31: Idle
<< Press ESC key to return to previous menu >>
Note: If you want to perform the Time Slot Assignment Setup, you should do the TSI Map Setup in the
AM3440 controller menu ((S) System Setup > (C) TSI Map Setup) first.
7.3.3. Bundle IP Setup
¾ Command Path
Main Menu > (T) Time Slot IP Assignment > (C) Bundle IP
Setup
¾ Function
Enables users to key in the source IP address, subnet Mask,
and Gateway IP for the bundle
¾ Bundle IP Setup Screen:
SLOT 2 TDMoE === Bundle IP Setup === 17:01:39 12/31/2009
ARROW KEYS: CURSOR MOVE, Please Input: nnn.nnn.nnn.nnn, BACKSPACE to edit
Src. IP Address : 000.000.000.000
Subnet Mask : 000.000.000.000
Gateway IP : 000.000.000.000
<< Press ESC key to return to previous menu >>
Table 7-24 Bundle IP Setup
Field Setting Options Default
Source IP Address
Subnet Mask
Gateway IP
Setup by User 000.000.000.000
7.3.4. Time Slot IP Assignment
¾ Command Path
Main Menu > (T) Time Slot IP Assignment > (D) Time Slot IP
Assignment
¾ Function
Enables users to change UDP settings for a port
