Loop Telecom AM3440 series User Manual

CHAPTER 7 SYSTEM SETUP
30
When the configuration is successfully changed, the screen will return to the previous menu.
7.2.2.1.2. Fixed Priority Setup
¾ Command Path
Main Menu > (S) System Setup > (C) QoS Setup > (A) Class of
Service > (B) Fixed Priority Setup
¾ Function
Enables users to change the transmission priority of each port
¾ Description
By changing the transmission priority for each port, the user
can specify that the transmission priority for any port is high,
medium, or low.
Table 7-4 Fixed Priority Setup
Field Transmission priority Default
ETH1~4 P0, P1, P2, P3 P0
¾ Fixed Priority Setup Screens:
Using Tab to select one of the priorities for each port:
SLOT 2 TDMoE === Fixed Priority Setup === 13:17:01 12/31/2009
ARROW KEYS: CURSOR MOVE, TAB: ROLL OPTIONS
Transmission priority
ETH1: P0
ETH2: P0
ETH3: P0
ETH4: P0
NOTE: Priority:P3 > P2 > P1 > P0
<< Press ESC key to return to previous menu >>
After you choose the transmission priority, press Esc. A prompt will ask if you wish to change
configuration. Press Y to confirm.
Change configuration (Y/N)? (Note:to save,please use V-command)
When the configuration is successfully changed, the screen will return to the previous menu.
7.2.2.1.3. Vlan CoS Priority Setup
¾ Command Path
Main Menu > (S) System Setup > (C) Qos Setup > (A) Class of
Service > (C) Vlan CoS Priority Setup
¾ Function
Enables users to change the transmission priority for each CoS
priority
¾ Description
By changing the transmission priority for each class of service,
the user can specify that the transmission priority for any class
of service is high, medium, or low.
Table 7-5 Vlan CoS Priority Setup
CoS priority Transmission priority Default
0~7 P0, P1, P2, P3 P0
¾ Vlan CoS Priority Setup Screens:
Using Tab to select one of the priorities for each CoS priority:
