Loop Telecom AM3440 series User Manual

CHAPTER 1 PRODUCTION DESCRIPTION
5
Ethernet and QE1/T1 Protection
1.4. Specifications
Optical SFP Module Characteristic for Gigabit Ethernet(GbE)
SFP Optical
Module
Direction Data Rate Wavelength(nm) Connector Distance
MTAFW dual uni-directional fiber 1.25G 850 LC without M 550 m
MTAFD dual uni-directional fiber 1.25G 850 LC with DDM 550 M
MTBTD dual uni-directional fiber 1.25G 1310 LC with DDM 2 km
MTBTW dual uni-directional fiber 1.25G 1310 LC without DDM 2 km
PTB2W dual uni-directional fiber 1.25G 1310 LC without DDM 20 km
PTB4W dual uni-directional fiber 1.25G 1310 LC without DDM 40 km
PTC5W dual uni-directional fiber 1.25G 1550 LC without DDM 50 km
PTC6W dual uni-directional fiber 1.25G 1550 LC without DDM 60 km
PTC8W dual uni-directional fiber 1.25G 1550 LC without DDM 80 km
PTC9W dual uni-directional fiber 1.25G 1550 LC without DDM 90 km
PTCVW dual uni-directional fiber 1.25G 1550 LC without DDM 110 km
PTCXW dual uni-directional fiber 1.25G 1550 LC without DDM 120 km
PTB1D dual uni-directional fiber 1.25G 1310 LC with DDM 10 km
PTB3D dual uni-directional fiber 1.25G 1310 LC with DDM 30 km
PTB4D dual uni-directional fiber 1.25G 1310 LC with DDM 40 km
PTC5D dual uni-directional fiber 1.25G 1550 LC with DDM 50 km
PTC6D dual uni-directional fiber 1.25G 1550 LC with DDM 60 km
PTC8D dual uni-directional fiber 1.25G 1550 LC with DDM 80 km
PTC9D dual uni-directional fiber 1.25G 1550 LC with DDM 90 km
PTCVD dual uni-directional fiber 1.25G 1550 LC with DDM 110 km
PTCXD dual uni-directional fiber 1.25G 1550 LC with DDM 120 km
PKB1W dual uni-directional fiber 622Mbps~1.
25G
1310 LC with DDM 10 km
SFP Optical
Module
Direction Data Rate Wavelength(nm) Connector Distance
PTD1W Single bi-directional fiber 1.25G 1310nm LC without DDM 10 Km
PTE1W Single bi-directional fiber 1.25G 1550nm LC without DDM 10 Km
PTD2W Single bi-directional fiber 1.25G 1310nm LC without DDM 20 Km
PTE2W Single bi-directional fiber 1.25G 1550nm LC without DDM 20 Km
PTD4W Single bi-directional fiber 1.25G 1310nm LC without DDM 40 Km
PTE4W Single bi-directional fiber 1.25G 1550nm LC without DDM 40 Km
PTD6W Single bi-directional fiber 1.25G 1310nm LC without DDM 60 Km
PTE6W Single bi-directional fiber 1.25G 1310nm LC without DDM 60 Km
PTD1D Single bi-directional fiber 1.25G 1310nm LC with DDM 10 Km
PTE1D Single bi-directional fiber 1.25G 1550nm LC with DDM 10 Km
PTD2D Single bi-directional fiber 1.25G 1310nm LC with DDM 20 Km
AM3440-A/B/C AM3440-A/B/C
QE1/T1
TDMoE and QE1/T1
1+1 protection
Ethernet Radio
Ethernet Radio
TDMoE TDMoE
Master
Slave
Backup line
Leased line
QE1/T1
Master
Slave
