CHAPTER 7 SYSTEM SETUP
31
SLOT 2 TDMoE === Vlan Cos Priority Setup === 13:18:47 12/31/2009
ARROW KEYS: CURSOR MOVE, TAB: ROLL OPTIONS
Cos priority Transmission priority
0 P0
1 P0
2 P0
3 P0
4 P0
5 P0
6 P0
7 P0
NOTE: Priority:P3 > P2 > P1 > P0
<< Press ESC key to return to previous menu >>
After you choose the transmission priority for each tag priority, press Esc. A prompt will ask if you wish
to change configuration. Press Y to confirm.
Change configuration (Y/N)? (Note:to save,please use V-command)
When the configuration is successfully changed, the screen will return to the previous menu.
7.2.2.1.4. ToS Field Priority Setup
¾ Command Path
Main Menu > (S) System Setup > (C) Qos Setup > (A) Class of
Service > (D) ToS Field Priority Setup
¾ Function
Enables users to change the transmission priority for each ToS
priority
¾ Description
By changing the transmission priority for each type of service,
the user can specify that the transmission priority for any type
of service is high, medium, or low.
Table 7-6 ToS Field Priority Setup
ToS priority Transmission priority Default
0~7 P0, P1, P2, P3 P0
¾ ToS Field Priority Setup Screens:
Using Tab to select one of the priorities for each ToS priority:
SLOT 2 TDMoE === TOS field Priority Setup === 13:28:23 12/31/2009
ARROW KEYS: CURSOR MOVE, TAB: ROLL OPTIONS
Tos priority Transmission priority
0 P0
1 P0
2 P0
3 P0
4 P0
5 P0
6 P0
7 P0
NOTE: Priority:P3 > P2 > P1 > P0
<< Press ESC key to return to previous menu >>
After you choose the transmission priority for each tag priority, press Esc. A prompt will ask if you wish
to change configuration. Press Y to confirm.
Change configuration (Y/N)? (Note:to save,please use V-command)
