CHAPTER 6 SYSTEM STATUS
26
6.6.6. SFP Status
¾ Command Path
Main Menu > (N) Status & Statistics > (G) SFP Status
¾ Description
You will see selections ETH1 and ETH2 at the button of the
screen. Use arrow keys to select the action you need, then,
press Enter to show the detail information of the action you
choose.
¾ SFP Status Screens:
Use arrow keys to select an action and press Enter:
SLOT 2 TDMoE === SFP Status === 08:52:00 12/31/2009
Select Action >> *ETH1 ETH2
You will see the SFP status for the port you selected as shown below.
SLOT 1 TDMoE === SFP Status === 18:22:47 01/05/2010
Connector : Not available
Transceiver: OC 3, multi-mode short
Link Length: long distance(L)
Technology : Shortwave laser w/ OFC(SL)
Encoding : Not available
Length(9/125 mm fiber) : 12700 m
Length(50/125 mm fiber) : 1270 m
Length(62.5/125 mm fiber): 1270 m
Temperature: 127.490 degrees C
Vcc : 3.263 mV
Tx Bias : 65.278 mA
Tx Power: 3.263 mW
Rx Power: 3.263 mW
<< ESC key to return to previous menu, SPACE bar to refresh >>
6.7. Alarm History
¾ Command Path
Main Menu > (A) Alarm History
¾ Description
Display the alarm message been transmitted of the card
¾ Alarm History Screen:
SLOT 1 TDMoE === Alarm History === 18:21:28 01/05/2010
[TYPE] [PORT] [BUNDLE] [CURR-STATE] [COUNT] [THRESHOLD] [ALARM]
ETH4-LINK DOWN ALARM 1 MAJOR
<< ESC key to return to previous menu, SPACE bar to refresh >>
