CHAPTER 7 SYSTEM SETUP
49
¾ Alarm Setup Screen:
SLOT 2 TDMoE === Alarm Setup === 09:24:53 01/04/2010
ARROW KEYS: CURSOR MOVE, TAB: ROLL OPTIONS
[Type] [Alarm] [Threshold]
ARP/bundle DISABLE 00001
Rx-Lost/bundle DISABLE 00001
Cell-Lost/bundle DISABLE 00001
Underrun/bundle DISABLE 1
Overrun/bundle DISABLE 1
Ethernet Link Down DISABLE
<< Press ESC key to return to previous menu >>
Table 7-26 Alarm Setup
Type Alarm Threshold
Setting Options Default Setting Options Default
ARP/Bundle
Rx-Lost/Bundle
Cell-Lost/Bundle
1~65535
00001
Underrun/Bundle
Overrun/Bundle
Ethernet Link Down
Disable, Major,
Critical, Minor
Disable
7.5. Clear Alarm History
¾ Command Path
Main Menu > (R) Clear Alarm History
¾ Function
Enables users to clear alarm history
¾ Clear Alarm History Screen:
To clear alarm history, press R from the port menu. A prompt will ask if you are sure you want to clear
the alarm queue. Press Y for yes. The alarm queue will be cleared, and you will be returned to the port
menu. This procedure is complete.
SLOT 2 TDMoE === Port Menu === 09:40:30 01/04/2010
FPGA Version: Ver.A OSC Type: TCXO
Software Version: V1.01.02 05/03/2010
[DISPLAY] [SETUP]
1 -> 15-Min/1-Hr/7 Days Perf.Report L -> Loopback Setup
2 -> 15-Min/1-Day Perf.Report S -> System Setup
C -> System Configuration T -> Time Slot IP Assignment
J -> All Time Slot Assignment M -> Alarm Setup
H -> Time Slot IP Configuration R -> Clear Alarm History
N -> Status & Statistics X -> Clear Performance Data
A -> Alarm History W -> Firmware Upgrade
[LOG] [MISC]
U -> Choose Other Slot Y -> Unit Load Default
F -> Log Off [SETUP],[MISC] Menu Z -> Card Reset
O -> Log On [SETUP],[MISC] Menu
E -> Return to Controller Main Menu
>> Clear alarm queue of SLOT 2 - are you sure ? [Y/N]
