CHAPTER 7 SYSTEM SETUP
28
Table 7-1 Loopback Setup
Field Setting Options Default
Near-End Loopback OFF, Backplane, PLB, LLB,
Local
OFF
LB Port Trib1~4 Trib1
E1 CH01~CH32 i LB MAP
T1 CH01~CH24 i
7.2. System Setup
¾ Command Path
Main Menu > (S) System Setup
¾ Function
In System Setup section, you can change the original system
configuration.
¾ Description
There are seven options you can select from the System
Setup: (A) Miscellaneous Setup (C) Qos Setup (E) Ethernet
Port Setup (L) Ethernet Switch Setup (P) Link Aggregation
Setup (R) RSTP Setup (T) Tributary Setup.
7.2.1. Miscellaneous Setup
¾ Command Path
Main Menu > (S) System Setup > (A) Miscellaneous Setup
¾ Function
Enables users to change the active bundle time, time durations
of alarm filter and delay switch.
Table 7-2 Advanced Setup
Field Setting Options Default
Active Bundle Time(s) 1~99999999 00000090
Alarm Filter 0~180 000
Delay Switch 0~180 000
Recover Delay 0~180 000
¾ Advanced Setup Screen:
Use BACKSPACE to edit the active bundle time:
SLOT 2 TDMoE === Miscellaneous Setup === 10:09:15 12/31/2009
Please input decimal number (1~99999999), BACKSPACE to edit
Active Bundle Time(s): 00000090
[Protection]
Alarm Filter: 003
Delay Switch: 000
Recover Delay:000
<< Press ESC key to return to previous menu >>
Active Bundle Time Active bundle time is the period of time that the system tries to activate an
established but inactive bundle. A bundle is necessary between local and
remote devices to transmit TDMoE traffic. If the local device receives the
MAC address of the remote device through ARP Response (Address
Resolution Protocol), then the traffic can be steadily forwarded, and Active
Bundle Time will not be triggered. However, if the local device cannot
receive TDMoE traffic from the remote device, this situation is the so-called
“Remote Loss”. Hence, the local device will send ARP request frames and
request the MAC address of the remote device. Once a bundle is inactive,
this status would trigger its own Active Bundle Time in operation.
Alarm Filter When an alarm occurs, the system will monitor the alarm status. If the
alarm still exists after the configured time, the alarm queue will be issued.
