CHAPTER 9 Appendix B: 1 + 1 Protection between TDMoE and QE1/T1 Card
59
of the screen:
SLOT 1 TDMoE === Tributary Setup === 15:35:35 08/03/2011
ARROW KEYS: CURSOR MOVE, TAB: ROLL OPTIONS
Framing Mode : T1-ESF
CAS : Off
Remote Loss : Continue
NOTE: Send Packet after remote unit is undetected
Warning!! If you need to change FRAME and CAS,
Please clear TSI MAP (MAP 1~4) of this port and delete bundle first.
<< Press ESC key to return to previous menu >>
9.2.3. Step 3: Configure Bundle IP
Once the framing mode setup is accomplished, the next step is to configure the bundle IP, including
Source IP Address, Subnet Mask, and Gateway IP.
¾ Command Path: TDMoE Main Menu > (T) Time Slot IP Assignment > (C) Bundle IP Setup
SLOT 1 TDMoE === Bundle IP Setup === 15:36:23 08/03/2011
ARROW KEYS: CURSOR MOVE, Please Input: nnn.nnn.nnn.nnn, BACKSPACE to edit
Src. IP Address : 192.168.014.100
Subnet Mask : 255.255.255.000
Gateway IP : 192.168.014.254
<< Press ESC key to return to previous menu >>
NOTE: For AM3440#2, the source IP Address is configured as 192.168.014.200 as an example.
To check the Bundle IP setting, users can go to Bundle IP Display (TDMoE Main Menu > (H) Time Slot
IP Configuration > (C) Bundle IP Display)).
9.2.4. Step 4: Assign Timeslots to an Interface
After Configuring the Bundle IP, the following step is to assign bundles to the timeslots. Each tributary
interface can be assigned more than one bundles.
¾ Command Path: TDMoE Main Menu > (T) Time Slot IP Assignment > (B) Time Slot Assignment
Setup
SLOT 1 TDMoE === Time Slot Assignment Setup === 15:40:52 08/03/2011
ARROW KEYS: CURSOR MOVE, TAB: ROLL OPTIONS
Port:Trib1
TS0 : Idle TS16: Bundle0
TS1 : Bundle0 TS17: Bundle0
TS2 : Bundle0 TS18: Bundle0
TS3 : Bundle0 TS19: Bundle0
TS4 : Bundle0 TS20: Bundle0
TS5 : Bundle0 TS21: Bundle0
TS6 : Bundle0 TS22: Bundle0
TS7 : Bundle0 TS23: Bundle0
TS8 : Bundle0 TS24: Bundle0
TS9 : Bundle0
TS10: Bundle0
To Next Page
