CHAPTER 6 SYSTEM STATUS
18
6.3.1. Miscellaneous Display
¾ Command Path
Main Menu > (C) System Configuration > (A) Miscellaneous
Display
¾ Description
Display the active bundle time, alarm filter, and delay switch
time
6.3.2. QoS Display
¾ Command Path
Main Menu > (C) System Configuration > (C) QoS Display
¾ Description
There are three options you can select from the QoS Display:
(A) Class of Service (B) Transmission Scheduling (C) Rate
Control Display.
6.3.2.1. Class of Service
¾ Command Path
Main Menu > (C) System Configuration > (C) Qos Display > (A)
Class of Service
¾ Description
There are four options you can select from the Class of
Service: (A) Priority Mode Display (B) Fixed Priority Display (C)
Vlan CoS Priority Display (D) ToS Field Priority Display.
6.3.2.1.1. Priority Mode Display
¾ Command Path
Main Menu > (C) System Configuration > (C) Qos Display > (A)
Class of Service > (A) Priority Mode Display
¾ Description
Display the priority mode of Ethernet 1~4
6.3.2.1.2. Fixed Priority Display
¾ Command Path
Main Menu > (C) System Configuration > (C) Qos Display > (A)
Class of Service > (B) Fixed Priority Display
¾ Description
Display the transmission priority of Ethernet 1~4
6.3.2.1.3. Vlan CoS Priority Display
¾ Command Path
Main Menu > (C) System Configuration > (C) Qos Display > (A)
Class of Service > (C) Vlan CoS Priority Display
¾ Description
Display the CoS priority value and its transmission priority
6.3.2.1.4. ToS Field Priority Display
¾ Command Path
Main Menu > (C) System Configuration > (C) Qos Display > (A)
Class of Service > (D) ToS field Priority Display
¾ Description
Display the ToS priority value and its transmission priority
6.3.2.2. Transmission Scheduling
¾ Command Path
Main Menu > (C) System Configuration > (C) Qos Display > (B)
Transmission Scheduling
¾ Description
There are three options you can select from the Transmission
Scheduling: (A) Flow Control Display (B) Scheduling Algorithm
To Next Page
