Loop Telecom AM3440 series - Table 7-25 Time Slot IP Assignment

CHAPTER 7 SYSTEM SETUP
47
14 31
15
16
<< Press ESC key to return to main menu or save system setup >>
After configured it, press “Y” or “N” to confirm it.
are you sure [Y/N] ?
After confirming to save the configuration, the screen will be shown as below:
SLOT 2 TDMoE === Time Slot IP Assignment === 09:00:43 01/06/2010
ARROW KEYS: CURSOR MOVE, TAB: ROLL OPTIONS
Port : Trib1
Bundle ID : 00 PO/TS TS PO/TS TS BNDL ID/UDP NUM Dest IP Address
Format : AAL1 ===== == ===== == =============== ===============
ToS : 000 1 0 0 1 17 17 0 1 001.001.001.002
UDP Number : 00001 1 1 1 1 18 18
Dest IP Addr: 001.001.001.002 1 2 2 1 19 19 Cell Num Jitter Delay Jitter Size
Stratum : 3 1 3 3 1 20 20 ======== =========== ============
Cell in Bundle : 05 1 4 4 1 21 21 5 20 256
Jitter Delay : 020 1 5 5 1 22 22
Jitter Size : 256 1 6 6 1 23 23
VLAN : OFF 1 7 7 1 24 24
CVLAN ID : 1 8 8 1 25 25
CVLAN Priority : 1 9 9 1 26 26
SVLAN ID : 1 10 10 1 27 27
SVLAN Priority : 1 11 11 1 28 28
Action : Add bundle 1 12 12 1 29 29
Confirm ? Yes 1 13 13 1 30 30
1 14 14 1 31 31
1 15 15
1 16 16
<< Press ESC key to return to main menu or save system setup >>
Table 7-25 Time Slot IP Assignment
Field Setting Options Default
Port Trib1~4 Trib1
Bundle ID E1 0~31 00
T1 0~24 00
Unframe AAL1, SAToP Format
Frame AAL1, CESoPSN
AAL1
ToS 0~255 000
UDP Number 1~65535 00000
Dest IP Addr. Setup by User 000.000.000.000
Stratum 1, 2, 3, 3E, 4 3
When Format is AAL1
Cell in Bundle 1~30 0005
When Format is CESoPSN
Number of Frame 1,2,3,4,6,8,12,24 0005
When Format is SAToP
Size in Bytes 24~1600 0300
Jitter Delay 1~512 020
Jitter size 1~512 256
Vlan OFF, 1-Vlan, 2-Vlan OFF
When Vlan is 1-Vlan
CVLAN ID 1~4094 0000
CVLAN Priority 0~7 0
When Vlan is 2-Vlan
CVLAN ID
SVLAN ID
1~4094 0000
CVLAN Priority
SVLAN Priority
0~7 0
Action Add Bundle, Delete All, Change Add Bundle
