Loop Telecom AM3440 series User Manual

CHAPTER 9 Appendix B: 1 + 1 Protection between TDMoE and QE1/T1 Card
60
TS11: Bundle0
TS12: Bundle0
TS13: Bundle0
TS14: Bundle0
TS15: Bundle0
<< Press ESC key to return to previous menu >>
To check the time slot assignment setting, users can go to Time Slot Assignment Display (TDMoE Main
Menu > (H) Time Slot IP Configuration > (B) Time Slot Assignment Display)).
9.2.5. Configure Parameters for Each Bundle
After the Time Slot Assignment Setup is fulfilled, users have to configure the parameters for each
bundle.
¾ Command Path: TDMoE Main Menu > (T) Time Slot IP Assignment > (D) Time Slot IP Assignment
Here, the destination IP Address is the IP Address of AM3440#2.
SLOT 1 TDMoE === Time Slot IP Assignment === 15:43:08 08/03/2011
ARROW KEYS: CURSOR MOVE, TAB: ROLL OPTIONS
Port : Trib1
Bundle ID : 00 PO/TS TS PO/TS TS BNDL ID/UDP NUM Dest IP Address
Format : AAL1 ===== == ===== == =============== ===============
ToS : 000 0 17 17 0 1 192.168.014.200
UDP Number : 00001 1 1 1 18 18
Dest IP Addr: 192.168.014.200 1 2 2 19 19 Cell Num Jitter Delay Jitter Size
Stratum : 3 1 3 3 20 20 ======== =========== ============
Cell in Bundle : 05 1 4 4 21 21 5 20 256
Jitter Delay : 64 1 5 5 22 22
Jitter Size : 256 1 6 6 23 23
VLAN : OFF 1 7 7 24 24
CVLAN ID : 1 8 8
CVLAN Priority : 1 9 9
SVLAN ID : 1 10 10
SVLAN Priority : 1 11 11
Action : Add bundle 1 12 12
Confirm ? Yes 1 13 13
1 14 14
1 15 15
16 16
<< Press ESC key to return to main menu or save system setup >>
NOTE:
1. The UDP number must be unique for all the bundles.
2. The Destination IP is the IP address for the remote TDMoE card to be mapped to.
3. For TDMoE card with PPM version, Stratum should always be 3.
4. For AM3440#2, the destination IP Address is the IP Address of AM3440#1, i.e.
192.168.014.100.
5. The Jitter Delay setting depends on the network environment. For detailed information,
please refer to Section 7.3.4 Time Slot IP Assignment.
To check the bundle settings, users can go to Time Slot IP Assignment Display (TDMoE Main Menu >
(H) Time Slot IP Configuration > (D) Time Slot IP Assignment Display)).
The entire process of setting up bundle(s) is complete. Users can ascertain whether the settings are
successfully configured through All Time Slot Assignment.
All Time Slot Assignment
¾ Command Path: TDMoE Main Menu > (J) All Time Slot Assignment
SLOT 1 TDMoE === All Time Slot Assignment === 15:44:20 08/03/2011
