CHAPTER 6 SYSTEM STATUS
17
6.2. 15-Min/1-Day Perf. Display
¾ Command Path
Main Menu > (2) 15-Min/1-Day Perf. Report
¾ Function
Display the 15-Min/1-Day performance report
Table 6-2 24-Hour Perf. Display
Field Setting Options Default
Register Port Trib1~4 Trib1
E1 00~31 00 Register Bundle
T1 00~24 00
Register Parameter Rx-Lost, J-UR, J-OR Rx-Lost
¾ ETH 24-Hour Perf. Report Screens:
Use arrow keys to select a port, a bundle and a parameter, and press Enter:
SLOT 2 TDMoE === 15-Min/1-Day Perf.Report === 13:02:08 12/30/2009
ARROW KEYS: CURSOR MOVE, TAB: ROLL OPTIONS
Register Port :Trib1
Register Bundle :00
Register Parameter:Rx-Lost
<< Press ESC key to return to previous menu >>
Then you will see the 15-Min/1-Day Perf. Report for the port, bundle, and parameter you select listed as
below:
SLOT 1 TDMoE === 15-Min/1-Day Perf.Report === 13:44:28 12/29/2010
Trib 1 Bundle 0 Rx-Lost
-- Valid Seconds in Current 15-Min Interval: 0 seconds
-- Valid 15-Min Intervals in Current 24-Hour Interval: 0
Rx-Lost J-UR J-OR
Current 15-Min Interval : 0 0 0
Current 24-Hour Interval : 3 0 0
-- Trib 1 Bundle 0 Rx-Lost Last 96 15-Min Interval :
01-08 --:-- > 0 0 0 0 0 0 0 0
09-16 --:-- > 0 0 0 0 0 0 0 0
17-24 --:-- > 0 0 0 0 0 0 0 0
25-32 --:-- > 0 0 0 0 0 0 0 0
33-40 --:-- > 0 0 0 0 0 0 0 0
41-48 --:-- > 0 0 0 0 0 0 0 0
49-56 --:-- > 0 0 0 0 0 0 0 0
57-64 --:-- > 3 ----- ----- ----- ----- ----- ----- -----
65-72 --:-- > ----- ----- ----- ----- ----- ----- ----- -----
73-80 --:-- > ----- ----- ----- ----- ----- ----- ----- -----
81-88 --:-- > ----- ----- ----- ----- ----- ----- ----- -----
89-96 --:-- > ----- ----- ----- ----- ----- ----- ----- -----
<< TAB key to show Statistics Report >>
<< ESC key to return to previous menu, SPACE bar to refresh >>
6.3. System Configuration
¾ Command Path
Main Menu > (C) System Configuration
¾ Description
There are seven options you can select from the System
Configuration menu: (A) Miscellaneous Display (C) QoS
Display (E) Ethernet Port Display (L) Ethernet Switch Display
(P) Link Aggregation Display (R) RSTP Display (T) Tributary
Display.
