CHAPTER 9 Appendix B: 1 + 1 Protection between TDMoE and QE1/T1 Card
63
NOTE: To make sure whether the MAP is activated, users can check the Current TSI MAP from the
System Main Menu.
¾ Command Path: AM3440 Controller Menu > (C) System Configuration > (D) Current TSI MAP
L
OOP AM3440-A === System Configuration (Current Map) ==15:51:10 08/03/2011
A
RROW KEYS: CURSOR MOVE, TAB: ROLL OPTIONS
C
urrent Map
S
lot Number: 1 TDMoE PO/TS D SL/PO TS PO/TS D SL/PO TS
P
ort Number:P1 NON-CAS ===== ========== ===== ==========
1 1 d 2 1 1 1 17 d 2 1 17
1 2 d 2 1 2 1 18 d 2 1 18
1 3 d 2 1 3 1 19 d 2 1 19
1 4 d 2 1 4 1 20 d 2 1 20
1 5 d 2 1 5 1 21 d 2 1 21
1 6 d 2 1 6 1 22 d 2 1 22
1 7 d 2 1 7 1 23 d 2 1 23
1 8 d 2 1 8 1 24 d 2 1 24
1 9 d 2 1 9
1 10 d 2 1 10
1 11 d 2 1 11
1 12 d 2 1 12
1 13 d 2 1 13
1 14 d 2 1 14
1 15 d 2 1 15
1 16 d 2 1 16
<
< Press ESC to return to previous menu >>
9.3.4. Configure Clock Source
After activating the TSI Map, the last step is to setup the clock source.
¾ Command Path: AM3440 Controller Menu > (S) System Setup > (K) Clock Source Setup
For AM3440#1, the Master/Second clock source is INTERNAL.
LOOP AM3440-A === System Setup (CLOCK-Normal Mode) ===14:14:07 09/09/2008
ARROW KEYS: CURSOR MOVE, TAB: ROLL OPTIONS
Master_Clk Source : INTERNAL Clock Hold-Over: ON
Second_Clk Source : INTERNAL
Current Clock : MASTER_CLK
Clk_Recover_Mode : AUTOMATIC
Clock Status : NORMAL
Ext. Clock Type : E1(75ohm)
Dual External Clock Protection : Disable
<< Press ESC key to return to previous menu >>
NOTE: For AM3440#2, the clock source is bundle clock. Hence, the Master clock source will be
SLOT_1 P1, and Second clock source is SLOT_2 P1.
After the entire process of setting up 1+1 protection for both AM3440#1 and AM3440#2 are complete,
users can ascertain whether the settings are successfully configured by checking the bundle status. If
the bundle status is active, then the configuration is accomplished.
