Loop Telecom AM3440 series User Manual

CHAPTER 9 Appendix B: 1 + 1 Protection between TDMoE and QE1/T1 Card
62
(Command Path: TDMoE Main Menu > (S) System Setup > (A) Miscellaneous
Setup).
2. 1+1 nonrevertive: After the working line switches from master to backup, it will not shift back to
the master even though the master line has recovered.
9.3.2. Configure TSI Map
After activating the 1+1 protection, users need to set the cross-connect map.
¾ Command Path: AM3440 Controller Menu > (S) System Setup > (C) TSI Map Setup.
L
OOP AM3440-A === System Setup (MAP) === 15:48:10 08/03/2011
A
RROW KEYS: CURSOR MOVE, TAB: ROLL OPTIONS
M
AP NO: MAP
_
1
Target Quad-T1 NON-CAS Source TDMoE NON-CAS
T
arget PO/TS D SL/PO TS PO/TS D SL/PO TS PO/TS D SL/PO TS PO/TS D SL/PO TS
S
lot : 10 ===== ========== ===== ========== ===== ========== ===== ==========
P
ort : P1 1 1 d 2 1 1 1 17 d 2 1 17 1 1 d 1 1 1 1 17 d 1 1 17
T
.S. : 01 1 2 d 2 1 2 1 18 d 2 1 18 1 2 d 1 1 2 1 18 d 1 1 18
1 3 d 2 1 3 1 19 d 2 1 19 1 3 d 1 1 3 1 19 d 1 1 19
1 4 d 2 1 4 1 20 d 2 1 20 1 4 d 1 1 4 1 20 d 1 1 20
T
.S.# : 24 1 5 d 2 1 5 1 21 d 2 1 21 1 5 d 1 1 5 1 21 d 1 1 21
C
lear : No 1 6 d 2 1 6 1 22 d 2 1 22 1 6 d 1 1 6 1 22 d 1 1 22
d
/v : d 1 7 d 2 1 7 1 23 d 2 1 23 1 7 d 1 1 7 1 23 d 1 1 23
1 8 d 2 1 8 1 24 d 2 1 24 1 8 d 1 1 8 1 24 d 1 1 24
1 9 d 2 1 9 1 9 d 1 1 9
S
ource 1 10 d 2 1 10 1 10 d 1 1 10
S
lot : 1 1 11 d 2 1 11 1 11 d 1 1 11
P
ort : P1 1 12 d 2 1 12 1 12 d 1 1 12
T
.S. : 01 1 13 d 2 1 13 1 13 d 1 1 13
1 14 d 2 1 14 1 14 d 1 1 14
C
onfirm?Yes 1 15 d 2 1 15 1 15 d 1 1 15
1 16 d 2 1 16 1 16 d 1 1 16
<< Press ESC to return to Controller Setup menu, then Press D to active >>
9.3.3. Activate TSI Map
After configuring the TSI MAP, the next step is to activate the TSI MAP.
¾ Command Path: AM3440 Controller Menu > (S) System Setup > (D) Select a New TSI MAP
Select the MAP that is configured, and Press ESC. A prompt will ask if you are sure.
LOOP AM3440-A === System Setup (New map) === 15:50:03 08/03/2011
ARROW KEYS: CURSOR MOVE, TAB: ROLL OPTIONS
Last activated TSI Map: MAP_1
Change to TSI Map : MAP_1
(This item will be ignored if anyone of the following is enabled.)
[TSI Map] switch start hr/min
Map1 DISABLE 00:00
Map2 DISABLE 00:00
Map3 DISABLE 00:00
Map4 DISABLE 00:00
<< Press ESC to return to previous menu >>
