CHAPTER 7 SYSTEM SETUP
40
¾ RSTP Configuration Screens:
When you enter this section, you will first see the RSTP Configuration menu. Use arrow keys to select
the action you need.
SLOT 2 TDMoE === RSTP Setup === 15:58:41 12/31/2009
Select Action >> *RSTP ETH1 ETH2 ETH3 ETH4
Press Enter key. You will see the screen below.
SLOT 2 TDMoE === RSTP Setup === 16:02:40 12/31/2009
ARROW KEYS: CURSOR MOVE, TAB: ROLL OPTIONS, ENTER: CHANGE RSTP STATE
RSTP State : OFF
<< Press ESC key to return to previous menu >>
If you change the RSTP State
from OFF to STP, you will see the screen as below.
SLOT 2 TDMoE === RSTP Setup === 09:52:14 01/05/2010
ARROW KEYS: CURSOR MOVE, TAB: ROLL OPTIONS, ENTER: CHANGE RSTP STATE
RSTP State : STP
<< Press ESC key to return to previous menu >>
If you change the RSTP State
from OFF to RSTP, you will see the screen as below. Note that the
acceptable value for the maximum age should be bigger or equal to twice the value of hello time+ 1,
and smaller or equal to twice the value of forward delay -1.
SLOT 2 TDMoE === RSTP Setup === 16:02:40 12/31/2009
ARROW KEYS: CURSOR MOVE, TAB: ROLL OPTIONS, ENTER: CHANGE RSTP STATE
RSTP State : RSTP
Priority : 32768
Hello Time : 02 (s)
Maximum Age : 20 (s)
Forward Delay: 15 (s)
NOTE: Acceptable value:
max-age >= 2 * (hello-time + 1)
max-age <= 2 * (forward-delay - 1)
<< Press ESC key to return to previous menu >>
