As you type the node address, it will be checked and the result of the syntax check is
indicated by the dialog icon and the text field. Press the “Save” – Button to save the node
address into the node list.
Existing nodes can be edited by double clicking on the row containing the node in the list.
Figure 118: Tried to save entry which is identical to an already existing one.
Note that the address is checked against double entries while saving and an error message
will appear if you try to add a new entry or change the address of an existing entry into an
address which already exists (see Figure 118). If you press OK here, entry number 2 will be
deleted and entry number 1 updated.
9.5.6.2 Import node list from LNS database
Press ‘A’ on the keyboard or choose the entry in the “Node List” menu to open the
“Automatically import nodes” – Dialog (see Figure 119).
You can choose to delete the current node list prior to import. If this option is not selected
only nodes not present in the current node list are added. Further the address format used to
contact the node can be selected. You can choose between the Subnet/Node address format
and the Unique Node ID (“Neuron ID”) address format.
LNS import is only available in on-line and off-line operation mode, but not in standalone
operation mode.
Figure 119: Import node list from LNS database.
9.5.6.3 Change order of node list
To change the order of the node list select the entries and move them up and down with the
arrows in the toolbar (see Figure 120). To select multiple items press the CTRL-key while
selecting.
