MERLIN LEGEND Communications System Release 6.1
System Programming Guide
555-661-111
Issue 1
August 1998
Programming Procedures
Page 3-21System Renumbering
3
When trunk or extension modules are removed from the control unit, the
remaining modules must be rearranged so that no empty slots remain. The
system does not acknowledge any modules installed after an empty slot;
therefore, if the system is renumbered, extensions are not assigned to extension
jacks after the empty slots.
NOTE:NOTE:NOTE:
Figure 3–1, Figure 3–2, and Figure 3–3 show the factory settings in the
gray spaces. Extensions can be renumbered to any number shown in the
white spaces.
Figure 3–1. 2-Digit Numbering
0 Operator Console (not flexible) 0
1 Extensions 10−19
2 Extensions 20−29
3 Extensions 30−39
4 Extensions 40−49
5 Extensions 50−59
6 Extensions 60−66 Extra
Extensions
6700−6842
6843−
6849
Extra MFMs/
Terminal Adapters
6850−6992
6993−
6999
7 Main Pool
70
MFMs/
Terminal Adapters
710−766
767−
769
Calling Groups
770–791,7920−7929
Paging
Groups
793−799
8 800
*
Trunks 801−880 Park
881−888
889
†
Pools
890−899
9 ARS Access (Hybrid/PBX Mode) / Idle Line Access 9
*
Listed Directory Number (QCC Queue)
†
Remote Access
NOTE: “0” and “10” are the same station.
