MERLIN LEGEND Communications System Release 6.1
System Programming Guide
555-661-111
Issue 1
August 1998
Programming Basics
Page 1-14Programming Procedures
1
Verifying Data Entry 1
You can use the Inspect feature to view the entries you save. An example of how
to use the Inspect feature begins with Figure 1–8
. The figure shows a data entry
screen with the first of two required extension numbers needed to assign analog
voice and data.
Figure 1–8. Inspect Example
After you enter and save , the system automatically assigns the next
sequential extension jack number. This extension jack pair does not appear on the
data entry screen; however, if you press Inspct (
on the PC), the pair
appears, as shown on the sample Inspect screen in Figure 1–9
.
Figure 1–9. Sample Inspect Screen
Whenever you want to return to the previous screen, select
([LW (
on the PC).
The Inspect feature also allows you to check a value currently programmed for a
feature. This is helpful when you are changing or modifying features. You can also
use it when you program sequential extensions or lines to verify the last number
programmed. See the
Feature Reference
for details about the Inspect feature.
'DWD9RLFH'DWD!
Selected Option
(QWHUYRLFHGDWDSDLU
Prompt
Extension entered
'HOHWH
%DFNVSDFH
([LW (QWHU
9RLFH'DWD3DLUV!
Inspect data displayed
([LW
