MERLIN LEGEND Communications System Release 6.1
System Programming Guide
555-661-111
Issue 1
August 1998
LED Displays
Page C-2
C
Table C–1. Line or Trunk Feature Status for MLX-20L Console
* LED Status is indicated on LEDs next to the 20 buttons below the display area of the system programming console,
or simulated on the computer screen when using SPM.
† This is the factory setting.
System
Programming
Menu Option
LED Status*
Green LED Red LED
Option ON OFF FLASHING ON OFF FLASHING
Lines Trunks Tie Lines
Inmode Incoming tie
line is
touch-tone
Incoming
tie line is
rotary dial†
Outmode Outgoing tie
line is
touch-tone
Outgoing
tie line is
rotary dial†
Dialtone Remote dial
tone†
Local dial
tone
Lines Trunks TT/LS
Disc
Outmode Line/Trunk is
touch-tone†
Line/trunk
is rotary dial
Lines Trunks Pools Trunk is
in pool
Trunk is not
in pool
Lines Trunks Toll Type Must dial 1 +
area code†
1 + dialing is
not needed
Lines Trunks Hold
Disconct
Long-450 ms† Short-50 ms
Lines Trunks LS-ID
Delay
LS-ID Delay
is on
LS-ID
Delay is off†
Extensions Lines
Trunks
Line/trunk or
pool is
assigned to
button
Line/trunk or
pool is not
assigned to
button
Trunk is
assigned
to a pool
