Lucent Technologies MERLIN LEGEND Release 6.1 System Programming

MERLIN LEGEND Communications System Release 6.1
System Programming Guide 555-661-111
Issue 1
August 1998
Programming Procedures
Page 3-161DID Trunks
3
3 we
DID Trunks 3
This section covers programming DID trunks and includes procedures for the
following:
■ Block Assignment
■ DID Trunk Type
■ Disconnect Time
■ Expected Digits
■ Delete Digits
■ Add Digits
■ Signaling
■ Invalid Destination
NOTE:NOTE:NOTE:
These procedures apply to Hybrid/PBX mode only.
Block Assignment 3
Use this procedure to assign each DID trunk connected to the system to either
Block 1 or Block 2.
Summary: Block Assignment 3
Programmable by System Manager
Mode Hybrid/PBX
Idle Condition Not required
Planning Form Form 3d, Incoming Trunks: DID
Factory Setting Block 1
Valid Entries Block 1, Block 2
Inspect Yes
Copy Option Yes
Console Procedure To program a single line/trunk:
/LQHV7UXQNV→','→%ORFN→Dial trunk block no.→ (QWHU→
EQWU\0RGH→Type the line/trunk no.→
(QWHU or 'HOHWH→ ([LW→([LW→([LW
To program a block of lines/trunks:
/LQHV7UXQNV→','→%ORFN→Dial trunk block no.→ (QWHU→
Select trunk lines→Toggle LED On/Off→(QWHU→
([LW→([LW→([LW
