Lucent Technologies MERLIN LEGEND Release 6.1 System Programming

MERLIN LEGEND Communications System Release 6.1
System Programming Guide 555-661-111
Issue 1
August 1998
Programming Procedures
Page 3-165DID Trunks
3
◆ Block Procedure
Console Display/Instructions Additional Information PC
! Specify the DID trunks associated with 20 buttons on the system
programming console.
Select
/LQHV 
/LQHV 
/LQHV 
/LQHV 
! Assign or remove the trunk.
Toggle the green LED on or off as required.
On = assign DID trunk to block
Off = remove DID trunk from block
! Return to the System Programming menu.
Select
([LW three times.

DID Trunk Type 3
Use this procedure to specify the DID trunk type as either immediate-start or wink-
start. Wink-start is more reliable if the local telephone company supports it.
Summary: DID Trunk Type 3
Programmable by System Manager
Mode Hybrid/PBX
Idle Condition DID trunk idle
Planning Form Form 3d, Incoming Trunks: DID
Factory Setting Wink-start
Valid Entries Immediate-start, Wink-start
Inspect No
Copy Option No
Console Procedure
/LQHV7UXQNV→','→7\SH→Dial trunk block no.→
(QWHU→,PPHG or :LQN→(QWHU→([LW→([LW
PC Procedure

→→→Type trunk block no.→→
or
→
→→
