MERLIN LEGEND Communications System Release 6.1
System Programming Guide
555-661-111
Issue 1
August 1998
Programming Procedures
Page 3-185PRI Facilities
3
The following rules apply to PRI tandem trunks in PBX or network mode:
■ A single unused B-channel group number is automatically assigned to all
23 B-channels on the trunk; B-channels may be removed or added (for
more information, see “B-Channel Groups” on page 3–190
).The group can
still exist, even if it includes no B-channels.
■ PRI Dial Plan Routing does not apply for incoming calls on the trunk.
Incoming routing is automatically set to Route Directly to UDP for
B-channels in the automatically assigned group; this cannot be changed as
long as the Legend-PBX or Legend-NTWK switch type is in effect (see
“Incoming Routing” on page 3–206
). However, local extensions need not
be included in the UDP Routing table.
■ PRI outgoing tables do not apply to outgoing calls on the trunk.
■ The system automatically assigns Electronic Tandem Network (ETN) as
the network service for the B-channel group that is automatically assigned
to the PRI tandem trunk; this setting cannot be changed as long as the
switch type is in effect (see “Network Service” on page 3–196
).
■ The Copy Telephone Number to Send setting is set to Do Not Copy for the
PRI tandem trunk B-channel group; this setting cannot be changed as long
as the switch type is in effect (see “Copy Telephone Number to Send” on
page 3–203).
Summary: Switch Type 3
Programmable by System Manager
Mode Hybrid/PBX
Idle Condition Not required
Planning Form Form 3b, Incoming Trunks: DS1 Connectivity (100D module)
Factory Setting 4ESS
Valid Entries Not applicable
Inspect Yes
Copy Option No
Console Procedure
/LQHV7UXQNV→35,→6ZLWFK7\SH→Dial slot no.→
(QWHU→Specify switch type→(QWHU→([LW→([LW
PC Procedure
→→→Type slot no.→→
Specify switch type→→→
To Next Page
