Lucent Technologies MERLIN LEGEND Release 6.1 System Programming

MERLIN LEGEND Communications System Release 6.1
System Programming Guide 555-661-111
Issue 1
August 1998
Programming Procedures
Page 3-206PRI Facilities
3
Incoming Routing 3
Use this procedure to specify whether incoming routing is either by line
appearance or according to dial plan. Dial Plan Routing is available in Hybrid/PBX
mode only.
In Release 6.0 and later systems, the Incoming Routing screen displays an
option, Route Directly to UDP (Uniform Dial Plan). In Release 6.0 and later
systems, setting the switch type to Legend-PBX or Legend-NTWK automatically
assigns Route Directly to UDP as the Incoming Routing option for the single
B-channel group associated with the Switch Type setting. As long as the switch
type for the slot of the PRI tandem trunk is set this way, you cannot change the
incoming routing for the group. This routing option cannot be selected for any
other switch type. For more information about switch types, see “Switch Type” on
page 3–184.
Summary: Incoming Routing 3
Programmable by System Manager
Mode Line appearance: Hybrid/PBX, Key; Dial Plan Routing or
Route Directly to UDP: Hybrid/PBX only
Idle Condition Not required
Planning Form Form 3b, Incoming Trunks: DS1 Connectivity (100D module)
Factory Setting Line appearance
Valid Entries Dial Plan Routing, Routing by Line Appearance,
Route Directly to UDP
Inspect No
Copy Option No
Console Procedure
/LQHV7UXQNV→35,→%&KDQQO*US→,QFRPLQJ5WJ→ Dial
B-channel group no.
→(QWHU→Specify routing
method
→(QWHU→([LW→([LW→([LW
PC Procedure

→→→→Type B-channel group no.→
→Specify routing method→ →→→
