Lucent Technologies MERLIN LEGEND Release 6.1 System Programming

MERLIN LEGEND Communications System Release 6.1
System Programming Guide 555-661-111
Issue 1
August 1998
Programming Procedures
Page 3-203PRI Facilities
3
Copy Telephone Number to Send 3
Use this procedure to indicate whether or not the telephone number to send to the
network (for calls going out over ISDN lines assigned to a B-channel group) is
copied from the number assigned to that channel.
NOTE:NOTE:NOTE:
In Release 6.0 and later systems (Hybrid/PBX mode only), setting the
switch type to Legend-PBX or Legend-Ntwk automatically assigns Copy
Number as the option for the single B-channel group associated with PRI
tandem trunk that you specified in the Switch Type setting. As long as the
switch type for the slot is set this way, you cannot change the Copy
programming. For more information about switch types, see “Switch Type”
on page 3–184.
Select
'R1RW&RS\3KRQH1XPEHU either when a telephone number to send is
assigned to each channel in the B-channel group or when no telephone number is
to be sent to the network. In the latter case, make sure that no telephone numbers
are assigned to any channels in the B-channel group by using the “Telephone
Number to Send” procedure.
Summary: Copy Telephone Number to Send 3
Programmable by System Manager
Mode Hybrid/PBX, Key
Idle Condition Not required
Planning Form Form 3b, Incoming Trunks: DS1 Connectivity (100D Module)
Factory Setting Do Not Copy
Valid Entries Do Not Copy, Copy
Inspect No
Copy Option No
Console Procedure
/LQHV7UXQNV→35,→%&KDQQO*US→&RS\1XPEHU→
Dial group no.→(QWHU→Specify copy or no copy→
(QWHU→([LW→([LW→([LW
PC Procedure

→→→→Type group no.→→
Specify copy or no copy→→→→
