MERLIN LEGEND Communications System Release 6.1
System Programming Guide
555-661-111
Issue 1
August 1998
Programming Procedures
Page 3-67Lines and Trunks
3
Hold Disconnect Interval 3
Use this procedure to specify the number of milliseconds before a loop-start
line/trunk is released when a caller on hold hangs up and abandons the call. This
can be specified as either a long interval (450 ms) or a short interval (50 ms). The
hold disconnect interval applies to loop-start trunks; it does not apply to emulated
loop-start trunks (T1 facility).
NOTES:
1. If the disconnect interval is longer than the telephone company setting,
the line is not released when a caller on hold hangs up.
2. Do not program a short interval unless the local telephone company’s
central office is the crossbar type.
3. Do not program a reliable disconnect for lines/trunks with a short hold
disconnect interval. This can cause active calls as well as lines/trunks on
hold to be disconnected. See “Disconnect Signaling Reliability” on page
61.
For more information on Hold Interval Disconnect and Reliable and Unreliable
Disconnect, see the
Feature Reference.
Summary: Hold Disconnect Interval 3
Programmable by System Manager
Mode All
Idle Condition Not required
Planning Form Form 2c, System Numbering: Line/Trunk Jacks
Factory Setting Long interval (450 ms)
Valid Entries Long interval, Short interval
Inspect No
Copy Option No
Console Procedure To program a single line/trunk:
/LQHV7UXQNV→More→+ROG'LVFQFW→Select entry
mode
→Dial no. of the line/trunk→(QWHU→([LW→([LW
To program a block of lines/trunks:
/LQHV7UXQNV→More→+ROG'LVFQFW→Select block of
lines/trunks
→Toggle LED On/Off→(QWHU→([LW→([LW
PC Procedure To program a single line/trunk:
→→→→Type no. of the line/trunk→
→→
To program a block of lines/trunks:
→→→Select block of lines/trunks→
Toggle letter * On/Off→→→
